Actuator type
AEL6221_
AEL6321_ _ AEL6323_ AEL6421_ AEL6422_
AEL6532_
AEL6631_
Supply voltage 230 Vac, 115 Vac, 24 Vac, 24 Vdc
Supply frequency
50 Hz / 60 Hz / continuous
Maximal power consumption VA
Note: power consumption is
relative to 50 / 60
Hz / continuous respectively
13
19 57 25 72
65
88
Current consumed by the
actuator
Current which is necessary
for the power supply
1 Amp - 24vac / dc
0.25 Amp - 110vac
0.15 Amp - 220vac
3 Amp - 24vac / dc
0.6 Amp - 110vac
0.3 Amp - 220vac
4 Amp - 24vac / dc
0.8 Amp - 110vac
0.4 Amp - 220vac
5 Amp - 24vac / dc
1 Amp - 110vac
0.5 Amp - 220vac
1 Amp - 24vac / dc
0.25 Amp - 110vac
0.15 Amp - 220vac
1 Amp - 24vac / dc
0.3 Amp - 110vac
0.2 Amp - 220vac
3 Amp - 24vac / dc
0.7 Amp - 110vac
0.35 Amp - 220vac
Stroke mm
50
50 50 50 50
65
95*
Actuator speed mm/s
Note: Speed is relative to
50 / 60 Hz / continuous
respectively
0.9 0.9 4.5 0.7 1.7
1.3 0.4
Enclosure rating IP65 (for outdoor installations adequate shelter)
Actuator trust kN
2.3
4.5 4.5 8 8
14
25
Ambient limits -20 °C to 60 °C
Analog position set valve
input
Adjustable: 0/4 - 20 mA or 0/2 - 10 Vdc
Positioner function
Dead-band ajustable between 0.5 - 5% of set value range,
maximum resolution 0.1 mA or 0.05 V at 50 mm stroke
Active valve position
feedback
Adjustable: 0/4 - 20 mA or 0/2 - 10 Vdc
Automatic commissioning
Drives to torque dependant stop(s) and moves throught the whole valve travel.
Autoscale of set value and feedback in accordance to valve travel
Characteristic curve
correction
Up to 16 interpolation points, input inccuracy 1%
Torque increase
Adjustable up to 150% torque for up to 2.5s to break away a valve in the end position
Status indication 2 LEDs under actuator cover
Internal fault monitoring
Torque, position set value, active position value, position, temperature of electonic board
Diagnostics function
Stores cumulated operation data (motor and total running time, number of motor starts) and
data sets of current values (set value, feedback value, torque, temperature)
4.3.17
Control valves
Electric actuators
Technical data
*Notes:
1. 115 Vac and 230 Vac models of the AEL6631_ have a stroke limited to 95 mm.
2. 24 Vac and 24 Vdc models of the AEL6631_ are capable of up to 100 mm stroke.
Optional extras:
Additional position switches - AEL6951 (NC) and AEL6952 (NO)
Local control - (non retrofitable for the AEL66_) - AEL6955 (2.3 to 14 kN) and AEL6956 (25 kN)
Fault indicator relay - AEL6973 (non retrofitable)
Communication software including data cable - AEL6957
Space heater - AEL6953 (24 Vac) and AEL6954 (115 Vac and 230 Vac)
Approvals
This equipment is CE marked and conforms to the following:
-
-
Page 2 of 9
TI-P358-23 CTLS Issue 6
AEL6 Series Smart Electric Actuators for DN15 to DN100 Control Valves
-
-
-
-
-
EEC regulation 89 / 336 - EEC for Electromagnetical compatibility and 72 / 23 - EEC for low voltage directive.
EN 61000-2-2/2001 and EN 61000-6-4 for EMC, and 61010-1/1995 for safety.
