Control valves
Electric actuators
How to use the sizing data:
The following tables supply guidance as to the sizing of the AEL6 series actuator when it is used on the Spira-trolTM K and L series valves.
Three conditions are illustrated in tabular form:
KE, LE, KEA - 2-port valve: Class IV shut-off - Providing shut-off of the valve to the requirements of BS 5793-4 (IEC 60534-4)
class IV.
KE, LE, KEA - 2-port valve: Class VI shut-off - Providing shut-off of the valve to the requirements of BS 5793-4 (IEC 60534-4)
class VI.
QL - 3-port valve: Class IV shut-off - Providing shut-off of the valve to the requirements of BS 5793-4 (IEC 60534-4) class IV.
To select a suitable actuator:
- Identify the column containing the valve size and gland material selected.
- Identify the maximum operating pressure condition, including any transient pressures likely to occur, within the selected column.
- Read back to the left hand side of the table to identify the suitable actuator for the application.
For conditions outside of those illustrated please contact Spirax Sarco.
Maximum differential pressures for modulating duties only –
KE, LE, KEA and LEA 2-port valves.
For pure control applications providing control across the full valve operating range, but not guaranteeing shut-off to a greater level than
the minimum flowrate based on the valve 50:1 turndown.
with PTFE or Graphite stem seal
Valve size
DN15 DN20
DN25
DN32
DN40 DN50 DN65
DN80
DN100
Kv 4.0 6.3
10
16 25 36 63
100 160
Valve travel
20 mm 30 mm
Actuator
Maximum differential pressure bar
AEL6221-
40.0
40.0
40.0
40.0 40.0
40.0
40.0
38.5
19.2 16.6
13.7
11.8
7.5
5.7 4.8 3.6
3.0
2.3
AEL6321- * 40.0
40.0
40.0
40.0
38.6 36.0
27.5
25.6
15.3
13.5 9.8 8.6
6.1
5.4
AEL6323- * 40.0
40.0
40.0
40.0
38.6 36.0
27.5
25.6
15.3
13.5 9.8 8.6
6.1
5.4
AEL6421- * 40.0
40.0 40.0 40.0
40.0 40.0
27.7 25.9 17.7 16.5
11.0 10.3
AEL6422- *
40.0
40.0
40.0 40.0
40.0
40.0
27.7
25.9 17.7 16.5
11.0
10.3
AEL6532-
40.0
40.0
40.0 40.0
40.0
40.0
40.0
40.0 31.3 30.1
19.5
18.8
AEL6631-
40.0 40.0
40.0 40.0 40.0 40.0
35.0 34.3
* Please note that although the AEL6321- and the AEL6323- have the same maximum differential pressure values, they have different
operating speeds. The same applies to the AEL6421- and the AEL6422-. Please refer to the technical data table on page 1 for full details.
with Bellows and PTFE or Graphite stem seal
Valve size
DN15 DN20 DN25 DN32 DN40 DN50 DN65 DN80
DN100
Kv
4.0 6.3 10 16 25 36 63 100
160
Valve travel
20 mm 30 mm
Actuator
Maximum differential pressure bar
AEL6221-
34.4
19.5
27.2
15.4
18.1
10.2
14.0 7.9
6.0
3.4
4.3
2.4
AEL6321- *
40.0
40.0
40.0
40.0
40.0
40.0
40.0 40.0
25.4
22.8
18.1
16.2
7.9
6.1
5.0
3.9
3.1
2.4
AEL6323- * 40.0
40.0 40.0
40.0 40.0
40.0 40.0 40.0
25.4 22.8
18.1 16.2
7.9 6.1
5.0 3.9
3.1 2.4
AEL6421- * 40.0 40.0
40.0 40.0
40.0 38.2
20.2 18.4
12.9 11.8
8.0 7.3
AEL6422- *
40.0 40.0
40.0
40.0
40.0
38.2
20.2
18.4
12.9
11.8
8.0
7.3
AEL6532-
40.0 40.0
40.0 40.0
26.5 25.4
16.5 15.8
AEL6631-
40.0
40.0
40.0
40.0
32.0
31.3
* Please note that although the AEL6321- and the AEL6323- have the same maximum differential pressure values, they have different
operating speeds. The same applies to the AEL6421- and the AEL6422-. Please refer to the technical data table on page 1 for full details.
TI-P358-23 CTLS Issue 6
Page 3 of 9
AEL6 Series Smart Electric Actuators for DN15 to DN100 Control Valves
