Description
The TD62LM and TD62M are maintainable high pressure
thermodynamic steam traps with integral strainer and a replaceable
seat to ease maintenance. They have been specifically designed for
mains drainage applications up to 62 bar g.
The TD62LM is specifically designed for relatively small condensate
loads on superheat and mains drainage applications. An insulating
cover is fitted as standard to prevent the trap being unduly influenced
by excessive heat loss when subjected to low ambient temperatures,
wind or rain. Body and cover castings are produced by a TÜV
approved foundry.
Standards
This product fully complies with the requirements of the European
Pressure Equipment Directive 97/23/EC.
Certification
This product is available with certification to EN 10204 3.1.
Note: All certification/inspection requirements must be stated at
the time of order placement.
5.7.43
Sizes and pipe connections
DN15, DN20 and DN25.
Standard flange EN 1092 PN100.
Pressure / temperature limits
5
9
11
2
8
1
0
7
���
���
���
���
���
�
Steam saturation
curve
�
��
��
��
��
���
Pressure bar g
The product must not be used in this region.
The product should not be used in this region or beyond
its operating range as damage to the internals may occur.
Materials
No. Part
1 Body
2 Top cover
3 Bottom cover
4 Strainer screen
5 Insulating cover
6 Disc
7 Seat
8 Cover studs (top)
8A Cover studs (bottom)
9 Cover nuts
10 Cover gaskets
11 Name-plate
13 Inner seat gasket
14 Outer seat gasket
15 Ferrule
Note: Item 15 (ferrule) is pressed into item 7 (seat).
Steam traps
Thermodynamic
TD62LM and TD62M
Thermodynamic Steam Traps
with Replaceable Seats EN Body (Flanged connections)
6
14
13
8A
9
15
4
1
10
3
TI-P068-19
ST Issue 8
T
e
m
p
e
r
a
t
u
r
e
°
C
Body design conditions
PMA Maximum allowable pressure
TMA Maximum allowable temperature
Minimum allowable temperature
PMO
Maximum operating pressure
for steam service
TMO Maximum operating temperature
Minimum operating temperature
PN100
98.1 bar g @ 300°C
525°C @ 42.7 bar g
-10°C
62 bar g @ 482°C
525°C @ 42.7 bar g
Steel
Steel
Steel
Stainless steel 100 mesh
316L
Aluminium
PMOB
Maximum operating
backpressure
0°C
TD62LM 50% of upstream pressure
*
*
*
Chromium steel
Chromium steel
Steel
DIN 17240 21 CrMoV 5 7
Steel
DIN 17240 21 CrMoV 5 7
Steel
DIN 17240 21 24 CrMo 5
Spirally wound stainless steel
with exfoliated graphite filler
Stainless steel
Spirally wound stainless steel
with exfoliated graphite filler
TD62M
TD62LM
TD62M
80% of upstream pressure
8 bar g
1.4 bar g
Designed for a maximum cold hydraulic test pressure of 150 bar g
Minimum operating pressure
Local regulations may restrict the use of this product to below the conditions quoted.
In the interests of development and improvement of the product, we reserve the right to change the specification without notice.
© Copyright 2009
Material
EN 10213-2 G17 CrMo5-5+QT
EN 10213-2 G17 CrMo5-5+QT
EN 10213-2 G17 CrMo5-5+QT
Spirally wound stainless steel
with exfoliated graphite filler
Stainless steel
