Mounting equipment hydraulic separators DN 20-32

Immersion sleeve

1⁄4" ext. thread x T = 60 mm

standard, chromed brass, for sensor, T = 60 mm

566002

Wall bracket for HeatBloC® DN 20 (

3⁄4")

Components: 2 wall bracket sets, mounting equipment

Possible wall distance: 70-100 mm, distance: 15 mm

For 5-fold modular distribution manifolds, we recommend to use two wall bracket sets.

3121

Wall bracket for modular distribution manifold - DN 25 (1") - DN 32 (1

1⁄4")

Components: 2 floor brackets (galvanized steel), 8 wall plugs, 8 screws, 2 screws for fixing

the distribution manifold onto the floor brackets

Distance of the pipe axis to the wall: A = 400 mm

34721

Mounting plate DN 20 (3⁄4")

Components: mounting plate, 2 gaskets, 2 x 1" nut, 2 x reducing nipple 1" ext. thread x

3⁄4" ext.thread; for installation with flat sealings under a modular distribution manifold

and for attaching wall brackets

3125

Mounting plate DN 25 (1")

Components: mounting plate, 2 gaskets, 2 x 1

1⁄2" nut, 2 x housing of coupling F 1" x

11⁄2" ext. thread

for installation with flat sealings under a modular distribution manifold and for attaching

wall brackets

3425

Mounting plate DN 32 (11⁄4")

Components: mounting plate, 2 gaskets, 2 x 2" nut for installation with flat sealings

under a modular distribution manifold and for attaching wall brackets

3725

Fill and drain valve - DN 15 (

1⁄2'')

solid design, with hose connector and cap, completely made of brass,

1⁄2" with self-

sealing counter nut

2260

Union nut DN 20 (

3⁄4")

Brass, to screw insertion pieces for soldering below distribution manifolds DN 20 (

3⁄4")

2055

Union nut DN 25 (1'')

Brass, to screw insertion pieces for soldering below distribution manifolds DN 25 (1")

2155

Union nut DN 32 (1

1⁄4'')

Brass, to screw insertion pieces for soldering below distribution manifolds DN 32 (1

1⁄4")

2156

Sealing for nut - DN 20 (

3⁄4")

asbestos-free, outside diameter: 30 mm, inside diameter: 21 mm, height: 2 mm

2057

Sealing for nut - DN 25 (1")

asbestos-free, outside diameter: 44 mm, inside diameter: 32 mm, height: 2 mm

2157

Sealing for nut - DN 32 (1

1⁄4")

asbestos-free, outside diameter: 50 mm, inside diameter: 38 mm, height: 2 mm

2158
