Distribution manifold DN 32 (1

1⁄4")

D

i

s

t

r

i

b

u

t

i

o

n

m

a

n

i

f

o

l

d

D

N

3

2

(

1

1⁄

4

"

)

Technical data

Distribution manifold DN 32

Connections

for

HeatBloC®s

Application range

● modular design

● for outputs up to 150 kW (for each boiler connection) at a temperature

difference of 20 K

Operating data

Max. operating pressure

Max. operating temperature

6 bar

110 °C

Dimensions

Nominal diameter

Height

Height insulation

Centre distance

Connection generator

Connection consumer

Materials

Valves and fittings

Gaskets

Insulation

DN 32 (1

1⁄4")

156 mm

156 mm

125 mm

2" ext. thread, flat sealing

(bottom),

2 x for boiler connection,

others plugged

1

1⁄4" PAW flange for nut 2"

(top)

Brass

EPDM / AFM34

EPP

Differential pressure diagram

Execution

2-fold

3-fold

4-fold

5-fold

6-fold

Kvs value

34

37

38

38

38

Width

625 mm

3

875 mm

5

1 125 mm

7

1 375 mm

9

1 625 mm

11

Item no.

37123

37133

37143

37153

37163

138
