Equipment for modular sytem DN 25

Wall bracket for modular distribution manifold - DN 25 (1") - DN 32 (1

1⁄4")

Components: 2 floor brackets (galvanized steel), 8 wall plugs, 8 screws, 2 screws for fixing

the distribution manifold onto the floor brackets

Distance of the pipe axis to the wall: A = 400 mm

Wall bracket set for installation of single heating circuits - DN 25 (1")

Components: 2 x 1

1⁄2" nut, mounting plate, wall bracket

possible wall distance: 155 mm

34721

3422SET

Immersion sleeve

1⁄2" ext. thread x T = 30 mm

self-sealing, with o-ring, polished brass, for sensor,

Immersion sleeve

1⁄4" ext. thread x T = 60 mm

standard, chromed brass, for sensor, T = 60 mm

Immersion sleeve

1⁄2" ext. thread x T = 60 mm

standard, chromed brass, with valve extension (25

Immersion sleeve

1⁄2" ext. thread x T = 100 mm

standard, chromed copper, for sensor, T = 100 mm

Cutting-ring compression fitting DN 25 (1"), d =
