Retrofit set cleaning stop

Description

Retrofit set cleaning stop

Cable J-Y(St)Y

Description

Cable J-Y(St)Y, 2x2x0,8 mm

Traverses

Article number

CONO610000

Description

Crossbar,

for CONTI shower heads CONHEAD

Version

Wall mounting

Article number

CONO093000

Retrofit set cleaning stop for electronic showers

Time-out of water flow activation during cleaning operations by placing the RC switch on the

underside of the shower panel, to the right or above the piezo button on the cover plate.

Notice:

Concealed showers and shower panels, integrated into the CNX Water Management System,

already include the cleaning stop function.

Consisting of:

•

•

•

Control electronics retrofit set

Reed contact

RC switch, magnet with handle

Version

Shower installation

S

h

o

w

e

r

s

A

s

s

e

c

c

o

r

i

e

s

Cable J-Y(St)Y, 2x2x0,8 mm

For electrical wiring of CONTI+ showers, lavatory faucets and urinal flush valves

Outside coat:

Outer diameter:

Temperature range:

PVC, grey

7 mm

-30 °C to 70 °C, shielding by foil

CONTI Sanitärarmaturen GmbH | Hauptstraße 98 | 35435 Wettenberg | Germany | phone +49 641 98221 0 | fax +49 641 98221 50

info@conti.plus | www.conti.plus | CONVKF1010EN | valid from 07/2021 | Subject to change without prior notice

177

Packaging unit

100 m

Article number

CONO220000

Crossbar, for CONTI+ shower

heads CONHEAD

For fastening in metal partitions, double

stud partitions and installation walls in

any profile thickness, with shortenable

installation width, galvanised

Consisting of:

•

1 Anchor rail, type 28/15, with a fix and

a movable side part

•

1 Mounting plate for shower head

connection

•

Installation width: variable 417-625 mm

Also usable with rail systems by manu-

facturers Geberit, Viega, TC Friatec, etc.

1 anchor rail 28/15x569

2 end

3 anchor screw M 8x20

4 hexagon screw M 8

5 disc 8,4x16

6 mounting panel
