tipolino exposed shower faucet D35, chromed, thermostat, piezo switch, battery
S
h
o
w
e
r
h
e
a
d
s
V
e
r
s
i
o
n
S
h
o
w
e
r
s
e
l
e
c
t
r
o
n
i
c
114
CONTI Sanitärarmaturen GmbH | Hauptstraße 98 | 35435 Wettenberg | Germany | phone +49 641 98221 0 | fax +49 641 98221 50
info@conti.plus | www.conti.plus | CONVKF1010EN | valid from 07/2021 | Subject to change without prior notice
Power supply
6 V/DC Lithium battery
waterproof encased
See chapter
shower heads
Hygienic flush
•
CONHEAD hand shower set
Article number
110.405.11
CONO040000
tipolino exposed shower faucet D35, chromed, thermostat, piezo switch,
battery, outlet downwards
Electronically controlled shower faucet for exposed installation with piezo switch:
•
Sturdy version; faucet body made of drawn brass, chromed
•
Microprocessor; reliable solenoid valve 6 V/DC ROBUST, bistable
(minimal level of water pressure surge)
•
Start/stop button (piezo switch)
•
Temperature adjustable with reliable thermostat cartridge with anti scald and auto-thermic
protection
•
24, 48 or 72 hour hygienic flush activatable with start/stop button
•
Including s-connectors 3/4‘‘ and rosettes (lockable s-connector optional)
•
Service APP compatible: readout of the stored operating data and function settings in each case
when connected to BLE Converte
Battery:
6 V Lithium 2CR5 (standard: life time up to 4 years)
Hygienic flush (battery):
Hygiene flush can be carried out in electronic showers by programming via the piezo push-
button per shower. 12, 24 or 72 h, deactivatable; factory setting: hygienic flush deactivated,
interval and water flow time adjustable after activation.
Technical data:
Operating pressure:
Flow rate:
Water temperature (max.):
Filter:
Follow-up time:
Hygienic flush time:
Engineering standards:
Optional accessories:
Note:
0,3-10,0 bar
ca. 12 l/m
80 °C
0,3 mm mesh size
45 s pre-set (adjustable with function key 2 s - 2 min)
According to water flow time
DIN EN 200; CE
550.070.11 Temperature handle 38 oC with override button
CONO100405 Hygiene flush pipe
Service APP only available in conjunction with BLE Converter -
no permanent evaluation option.
For connection via Service APP, the BLE Converter must be
ordered separately.
