CHAPTER 2 DEVICES FOR GAS

AMSV-R

Automatic ON-OFF normally closed class A gas solenoid valve with threaded connections. Quick

opening and closing with adjustable flow rate. Aluminium body. Coil with IP65 connector (1/2"-3/4"-

1"). Coil with IP54 electrical enclosure (1.1/4"-1.1/2"-2"). Suitable for manufactured gas, natural gas,

liquefied petroleum gas (LPG), non-aggressive gas and air.

Operating temperature range: -20 to 60°C.

Part number

Connec-

tions

021.0139.001

3/4"

021.0140.001

1"

021.0141.101

1.1/4"

021.0142.101

1.1/2"

021.0143.101

2"

Dimensions on page 341

AMSV-2R

Q.ty/ Box/

Box Carton

1

1

1

1

1

1

1

1

1

1

Type

AMSV205R

AMSV255R

AMSV325R

AMSV405R

AMSV505R

Description

Power supply 230 VAC. Max.

pressure 0.5 bar

Power supply 230 VAC. Max.

pressure 0.5 bar

Power supply 230 VAC. Max.

pressure 0.5 bar

Power supply 230 VAC. Max.

pressure 0.5 bar

Power supply 230 VAC. Max.

pressure 0.5 bar

€/unit

Automatic ON-OFF normally closed class A gas solenoid valve. Quick opening and closing with

adjustable flow rate. Aluminium body. Coil with IP54 connector. Suitable for manufactured gas,

natural gas, liquefied petroleum gas (LPG), non-aggressive gas and air.

Operating temperature range: -20 to 60°C.

Type

AMSV202R

AMSV252R

AMSV322R

AMSV402R

AMSV502R

Part number

Connec-

tions

021.0041.001

3/4"

021.0042.001

1"

021.0043.001

1.1/4"

021.0044.001

1.1/2"

021.0045.001

2"

Dimensions on page 341

Description

Power supply 230 VAC. Max.

pressure 0.2 bar

Power supply 230 VAC. Max.

pressure 0.2 bar

Power supply 230 VAC. Max.

pressure 0.2 bar

Power supply 230 VAC. Max.

pressure 0.2 bar

Power supply 230 VAC. Max.

pressure 0.2 bar

Q.ty/ Box/

Box Carton

1

1

1

1

1

1

1

1

1

1

€/unit

24
