Steam traps

Steam trap management

5.1.17

Materials

Head unit

Receiver / Repeater

Technical information

Head unit:

Available with post or

tethered head mountings.

Head casing

Sensor housing

Sensor

Clamp

Winged nut

LED enclosure

Sensor cable

Probe

Mounting Bracket

Sensor guide

PA12 glass filled

Stainless steel 316 / 304

PZT

Stainless steel 430 / 304

Stainless steel 316

PA12

FEP / PTFE insulation

Stainless steel

Stainless steel 430

Stainless steel 304

Casing

ABS

Integral battery

Maximum altitude

Ambient temperature range

Maximum pipe temperature

Maximum relative humidity

Enclosure rating

Output

Display

Operating modes

Lithium Thionyl Chloride

3 000 m (0.7 bar atmospheric)

-29 to +70 °C

425 °C

95%

IP65

Wireless 2.4 GHz (frequency range 2.405 GHz to 2.480 GHz)

LED

Trap monitoring unit - end device or repeater / end device

Maximum output transmitting power

Modulation type

Channel space

Antenna gain

PC

Power

Current

Connector

Maximum altitude

Ambient temperature range

Maximum relative humidity

Enclosure rating

Display

Output

Operating modes

System requirements

6.3 mW

QPSK

5 MHz

0 dBi

Windows XP .NET 3.5

Windows 7 .NET 4.5

Network switch or access to company LAN network

Mains powered 100 – 250 Vac, 50 – 60 Hz

ac – 0.5 A 100 Vac

dc – 1.5 A 12 V

ac – 2 pin IEC 320-C8

3 pin UK, US and European mains plug

dc – 2 pin IP65 connector

3 000 m (0.7 bar atmospheric)

-29 to +70 °C

95%

IP65 (Excluding external power supply)

LED

Wireless 2.4 GHz (frequency range 2.405 to 2.480 GHz), Ethernet.

Receiver or repeater

Receiver / Repeater

Page 2 of 5

TI-P014-02 EMM Issue 4

STAPS Wireless Steam Trap Monitoring System
