Turbine flowmeters
How to order the RIM10 flowmeter
Category
Description
Model
Connection
(4)
Extended stem
Pressure
transmitter
Output / Comms
Certifications
Display options
Rotor
For
replacement
rotors see
page 8
Maximum temperatures
for liquid, steam or
gas service
RIM10-600 and
RIM10-700
RIM10-700 and
RIM10-700H
RIM10-900 and
RIM10-900H
RIM10-700 and
RIM10-700H
RIM10-900 and
RIM10-900H
No pressure transmitter
RIM10-600,
RIM10-700 and
RIM10-900
RIM10-700 and 700H
RIM10-900 and 900H
Special scaling requests
Standard outputs
Options A and B are only
available with Standard
and FM Certifications
Digital comms
BACNet MS/TP is only
available with Standard
and FM Certifications
Standard
(3)
FM
(5)
ATEX
(2)
CE
(1)
Local display
Remote display
Uni-directional
Bi-directional
RIM10-600 204°C (400°F)
RIM10-700 204°C (400°F)
RIM10-900 204°C (400°F)
2" screwed male NPT
2" flanged ASME 150
2" flanged ASME 300
2" flanged ASME 600
2" flanged ASME 900
3" flanged ASME 150
3" flanged ASME 300
Standard length
30 cm (1 ft) extension
above 260°C (500°F)
Suffix code
RIM10-600
RIM10-700 or 700H
RIM10-900 or 900H
NPT
2AB
2AD
2AE
2AF
3AB
3AD
XX
E1
E2
XX
050
100
150
200
250
500
Contact Spirax Sarco
A
B
D
E
0
3
4
5
S
A
B
C
000
025
050
100
G6
G5
G4
G3
G2
G1
L1
G5B
G4B
G3B
G2B
G1B
L1B
RIM10-700H 315°C (600°F)
RIM10-900H 400°C (750°F)
Note: A 3" flange
connection is recommended
when the extended stems
are used.
required for operating temperatures
Optional 60 cm (2 ft) extension gas and steam applications only
0to
0to
0to
0to
0to
0to
3.44 bar g
6.89 bar g
10.34 bar g
13.79 bar g
17.24 bar g
34.47 bar g
(0 to 50 psi g)
(0to100psig)
(0to150psig)
(0to200psig)
(0to250psig)
(0to500psig)
1each(4-20mA),1eachPulse
1 each (4 - 20 mA), 1 each Pulse, 2 each Relay
3 each (4 - 20 mA), 1 each Pulse
3 each (4 - 20 mA), 1 each Pulse, 2 each Relay
No Digital Bus Communications
Modbus IP / Modbus RS485
BACNet MS / TP
BACNet MS / TP / Modbus IP
with 25 ft
with 50 ft
with 100 ft
(7.6 m) of cable
(4)
(15.2 m) of cable
(4)
(30.4 m) of cable
(4)
Rotor 150-005-B-DEV (G6 Uni-directional)
Rotor 150-010-B-DEV (G5 Uni-directional)
Rotor 150-015-B-DEV (G4 Uni-directional)
Rotor 150-020-B-DEV (G3 Uni-directional)
Rotor 150-030-B-DEV (G2 Uni-directional)
Rotor 150-040-B-DEV (G1 Uni-directional)
Rotor 150-040-B-CSJ (L1 Uni-directional)
Rotor 150-010-B-DEV (G5B Bi-directional)
Rotor 150-015-B-DEV (G4B Bi-directional)
Rotor 150-020-B-DEV (G3B Bi-directional)
Rotor 150-030-B-DEV (G2B Bi-directional)
Rotor 150-040-B-DEV (G1B Bi-directional)
Rotor 150-040-B-CSJ (L1 B Bi-directional)
Nomenclature selection example:
Notes:
All electronics come with a magnetic wand for local programming.
1
RIM10 that are CE Approved meet with the:
European Pressure Equipment Directive 97 / 23 / EC - Select option 'C' from Approvals.
2
RIM10 with ATEX Approval that includes CE approval meet with the:
European Pressure Equipment Directive 97 / 23 / EC - Select option 'B' from Approvals.
3
Electrical enclosure rating is NEMA 4X for watertight and dust tight requirements.
4
PN flanges are available upon request. Contact Spirax Sarco.
5
FMus Certification (FMc is Pending).
TI-P198-01 MI Issue 5
RIM10 Series Rotor Insertion Flowmeters
