MF2M

Monnier Miniature

Compressed Air Filter

Local regulations may restrict the use of this product to below the conditions quoted.

In the interests of development and improvement of the product, we reserve the right to change the specification without notice.

© Copyright 2012

Filters

TI-P504-01

CH Issue 2

Manual

Drain

International Symbol

Description

The MF2M Monnier miniature compressed air filter provides high

quality compressed air for general purpose pneumatic applications.

Principal features:

- Compact unit suitable where space is limited and air flow is small.

- Multi-bladed whirl disc for improved moisture separation.

- Polycarbonate bowl.

- Long life 5 μm element.

- External black anodised finish.

Optional extras

For further technical information regarding the following options see

page 2:

- Type 3 mounting bracket.

- Easy fit stainless steel bowl guard.

Sizes and pipe connections

1⁄4" screwed BSP (BS 21-Rp).

Operating limits

Maximum working pressure

Maximum working temperature

10 bar g

50°C

Materials

Part

Bowl

Head

Element

Seals

Bowl guard

Material

Polycarbonate

Aluminium

Sintered polypropylene

Nitrile rubber

Stainless steel

Dimensions (approximate) in mm and kg

A

B

C

E

E1

Weight

10

98

38

25

76

0.155

C

Capacities

Air flow scfm

A

B

E Without bowl guard

E1 With bowl guard

Withdrawal distance:

Air flow dm3/s
