Hosedown Gun, Hose and Hose Rack
Gun
Description
The Spirax Sarco hosedown gun is designed for use on any hot or
cold water wash down and cleaning hose application. When the
trigger is released water flow ceases which can save up to 60% of
your hosed water cost.
Sizes
1⁄2" gun with
8
" internals for use with 1⁄2" hosedown station
3⁄4" gun with
9
" internals for use with 3⁄4" hosedown station
12
Gun
The hosedown guns have a 1⁄2" NPT female connection, which
Connections
Rack
accepts the swivel coupling that is pre-fitted to the hose.
and
11
hose
Limiting conditions
Body design conditions
Maximum design temperature
Maximum working pressure
Maximum operating temperature
Materials
No. Part
Material
1 Insulated covers Rubber
2 Body
Brass
Ms58
PN25
100°C
10 bar g
100°C
Stainless steel
Nylon coated brass
Stainless steel
Niro Wnr.4305
Ms58
Niro Wnr.4305
Ms58
EPDM 90 Schore
It 200
Perbunan
PVC / Nitrile
Perbunan
3 Piston
4 Lever handle
5 Spring
6 Linkage
Brass
7 Piston seal
Rubber
8 Gasket
Klingerit
9 'O' ring
Rubber
10 Hose
Reinforced EPDM
11 Hose protector
Rubber
12 Hose rack
Stainless steel
How to order
Example: 1 off Spirax Sarco 1⁄2" hosedown gun.
1
2
593
7
8
Hose
The Spirax Sarco hose is suitable for conveying steam, hot and cold
water. It is a dairy washdown steam hose rated to 170°C for steam
conditions.
Sizes
1⁄2" x 20 m dairy quality hose complete with crimped on 1⁄2" swivel
coupling.
3⁄4" x 20 m dairy quality hose complete with crimped on 3⁄4" swivel
coupling.
Connections
Hose coupling have a 1⁄2" NPT male taper thread to connect into
gun. See Installation and Maintenance Instructions IM-P157-03 for
connection procedure.
Description
6
4
Limiting conditions
Maximum working pressure
Maximum working temperature for hot water
7 bar g
95°C
How to order
Example: 1 off Spirax Sarco 1⁄2" x 20 m dairy quality hose complete
with crimped swivel coupling and hose protectors.
Local regulations may restrict the use of this product to below the conditions quoted.
In the interests of development and improvement of the product, we reserve the right to change the specification.
