Free discharge capacity

For air at 16 °C

��

��

��

������

������

������

������

������

������

������������������������

��

��

�

�

����

��

Differential pressure bar (x 100 = kPa)

equation:

289

273 + T (T is the actual temperature in °C)

Pipeline ancillaries

Air vents and air eliminators

If the temperature of the air differs from 16 °C, the discharge capacity from the graph can be corrected by multiplying it by the following

It may be assumed that the temperature of the air is equal to the temperature of the water.

Dimensions/weight (approximate) in mm and kg

Version

AE30, AE30A

AE30B, AE30C

A

B

56

105

56

105

C

10

10

D

Weight

-

0.7

155

0.9

A

C

7.12.18

B

D

Safety information, installation and maintenance

For full details see the Installation and Maintenance Instructions (IM-P017-08) supplied with the product.

Installation note:

The automatic air eliminator/air vent should be installed vertically with the inlet at the bottom. We recommend piping the discharge from

the air eliminator/air vent to a suitable drainpoint.

How to order

Example: 1 off Spirax Sarco 1⁄2" AE30C automatic air eliminator with check valve and lockshield valve screwed BSP.

TI-P017-07 ST Issue 14

Page 3 of 4

AE30, AE30A, AE30B and AE30C Automatic Air Eliminators/Air and Gas Vents for Liquid Systems
