Pipeline ancillaries

Separators and insulation jackets

Dimensions, weights and volumes

(approximate) in mm, kg and litres

Recommended tightening torques

11⁄4"

111 156 89 304 1⁄2" 1"

60

9.0

1.5

Item

Size

Size

A

B

C

D

E

F

G Weight Volume

11⁄2"

111 156 89 304 1⁄2" 1"

60

9.0

1.5

or

mm

N m

150 - 165

2"

146

205 117 397 1⁄2" 1"

71

17.0

3.2

2

2 Inspection opening (2" only)

2"

46 A/F

M56

B

A

Separator drain tapping F

G

D

C

Drain E

Safety information, installation and maintenance

For full details see the Installation and Maintenance Instructions (IM-P023-55) supplied with the product.

Installation note:

Install in a horizontal pipeline with the drain directly below. Note: To ensure that any separated liquid is drained away quickly, a suitable

liquid drainer or steam trap must be connected to the drain connection 'E' - consult Spirax Sarco for further details.

Disposal

This product is recyclable. No ecological hazard is anticipated with the disposal of this product, providing due care is taken.

How to order

Example: 1 off 2" Spirax Sarco S12 separator with SG iron body having screwed BSP connections.

S12 SG Iron Separator (Screwed)
