Pressure / temperature limits
������
A
BC
D
������
E
E
������
����
8
2
3
7
�
�
E
B
C
D
������
��
��
�������� ����
����
���� ����
5
4
6
1
8
7
5
10
6
1
8
Pressure bar g
��������
The product must not be used in this region.
A-B-B Flanged PN10.
A-C-C Maximum allowable pressure for the DN80H.
A-D-D Screwed BSP or NPT, flanged PN16 and ASME 150.
E-E-E Maximum operating limits for sizes DN100 to DN200.
PN16
16 bar g
16 bar g
12 bar g
10 bar g
DN8 - DN80
178°C @ 8.5 bar g
DN100 - DN200 150°C @ 8.1 bar g
Minimum allowable temperature
-20°C
DN8 - DN80
8.5 bar g @ 178°C
DN100 - DN200 8.1 bar g @ 150°C
DN8 - DN80
178°C @ 8.5 bar g
DN100 - DN200 150°C @ 8.1 bar g
Body design rating
PMA
Maximum allowable
pressure
DN80 (3")
L version
H version
DN100 - DN200
Minimum operating temperature
∆PMX Maximum differential pressure
DN8 - DN65 (1⁄4" - 21⁄2")
Pipeline ancillaries
Strainers and filters
T
e
m
p
e
r
a
t
u
r
e
°
C
TMA
Maximum allowable
temperature
* PMO
Maximum operating
pressure
DN8 to DN80
TMO
Maximum operating
temperature
8
2
Designed for a maximum cold
7.7.75
hydraulic test pressure of:
Materials
No. Part
1 Filter housing bowl
2 Filter housing head
3 Housing seal
4 Housing ring (DN8 - DN80)
5 CSF16-A filter element
6 Filter element seal (2 off)
7 Plug
8 Gasket
9 Flange
10
Bolts and nuts
(DN100 - DN200)
DN8 - DN65 (1⁄4" to 21⁄2")
DN80 (3")
L version
H version
0°C
5 bar g
27.5 bar g
27.5 bar g
20.6 bar g
18.3 bar g
TI-P185-11 ST Issue 2
CSF16 and CSF16T Stainless Steel Sterile Air Filters
Page 2 of 5
DN100 - DN200
Materials
Stainless steel
Stainless steel
CSF16
1.4301
CSF16T 1.4404
CSF16
1.4301
CSF16T 1.4404
For sizes DN8 to DN80
EPM is supplied as standard.
For sizes DN100 to DN200
PTFE spirally wound gasket with
stainless steel inner and outer rim
support is supplied as standard -
No other option is available.
Stainless steel
1.4301
Filter medium
Borosilicate
3
Outer core
End cap
Silicone VMQ
PTFE
Stainless steel
Stainless steel
1.4301
1.4301
Stainless steel
CSF16
1.4301
CSF16T 1.4404
1.4541
A2 - 70
DN100 to DN200
