Pipeline ancillaries

Strainers and filters

Pressure / temperature limits - ASME

������

A,B

������

������

������

C

The product must not be used in

this region or beyond the parameter

of the PMA or TMA of the relative

end connection.

Steam

saturation

curve

B

C

Flanged:

ASME Class 150

ASME Class 300

������

������

��

������

��

����

����

����

����

��������

Pressure bar g

A - B - B

A - C - C

ASME 150

ASME 300

Body design condition

PMA Maximum allowable pressure

TMA Maximum allowable temperature

Minimum allowable temperature

ASME Class 150

19 bar g @ 38°C

538°C @ 1.4 bar g

-29°C

13.3 bar g @ 195°C

538°C @ 1.4 bar g

-29°C

28.5 bar g

ASME Class 300

49.6 bar g @ 38°C

538°C @ 24.4 bar g

-29°C

33 bar g @ 241°C

538°C @ 24.4 bar g

-29°C

74.4 bar g

PMO Maximum operating pressure for saturated steam service

TMO Maximum operating temperature

Minimum operating temperature

Designed for a maximum cold hydraulic test pressure of:

Body design condition

PMA Maximum allowable pressure

TMA Maximum allowable temperature

Minimum allowable temperature

PMO Maximum operating pressure for saturated steam service

TMO Maximum operating temperature

Minimum operating temperature

Designed for a maximum cold hydraulic test pressure of:
