Pipeline ancillaries
Strainers and filters
Dimensions / weights (approximate) in mm and kg
Size
A
100% column = The standard unit
(100%)
(150%)
(200%)
B C D
DN40 - 11⁄2" 50 100 140 31 2 20
DN50 - 2" 68 115 150 44 2 32
DN65 - 21⁄2" 88 140 180 56 2 38
DN80 - 3" 108 165 230 67 2 50
DN100 - 4" 140 215 290 88 2 65
DN125 - 5" 173 268 355 117 2 83
DN150 - 6" 210 330 430 139 2 105
DN200 - 8" 282 430 585 181 3 145
DN250 - 10" 355 535 685 228 3 185
DN300 - 12" 427 635 825 276 3 225
DN350 - 14" 477 660 890 320 3 260
DN400 - 16" 558 750 990 368 5 300
DN450 - 18" 670 840 1 120 415 5 345
DN500 - 20" 704 940 1 245 466 5 380
DN600 - 24" 848 1 120 1 475 568 5
460
DN700 - 28" 993 1 538 2 072 686 5
550
A
A
E
B
D
B
B
TP2
TP3 and
Truncated
Flat Spacer
All
varients
TP1
Conical
conical
screen ring
C
C
C
F
Size
E
PN10
PN16
PN25
PN40
ASME 150 ASME 300 ASME 600
F
Weight *
PN
ASME
DN40 - 11⁄2"
88 88
88
88 80 90
90
102 0.30
0.24
DN50 - 2"
102 102
102
102 98 105
105
102 0.38
0.30
DN65 - 21⁄2"
122 122
122
122 117 124
124
102 0.45
0.40
DN80 - 3"
138 138
138
138 130 143
143
102 0.65
0.60
DN100 - 4"
158 158
162
162 168 175
187
102 1.00
0.60
DN125 - 5"
188 188
188
188 191 210
235
127 1.30
1.10
DN150 - 6"
212 212
218
218 216 245
260
127 2.00
1.60
DN200 - 8"
268 268
278
285 275 302
314
127 3.60
2.80
DN250 - 10"
320 320
335
345 333 356
394
153 5.00
3.90
DN300 - 12"
370 378
395
410 403 416
450
153 6.50
5.30
DN350 - 14" 430 438
450 465 445 479
486 153 8.40
6.40
DN400 - 16"
482 490
505
535 508 533
560
153 11.80
9.20
DN450 - 18"
532 550
555
560 543 591
605
203 12.40
11.60
DN500 - 20"
585 610
615
615 600 648
675
203 14.60
13.50
DN600 - 24"
685 725
720
735 711 768
784
203 20.30
18.60
DN700 - 28"
800 795
820
840 800 800
800
203 27.80
26.00
* Please note that the weights displayed are approximate and only applicable for the TP1 and TP2
Safety information, installation and maintenance
For full details see the installation and maintenance instructions
(IM-P169-07) supplied with the product.
Warning: Carry strainers with gloves.
Disposal: These products are recyclable. No ecologic hazard is
anticipated with disposal of these products providing due care is taken.
How to order
Example: 1 off Spirax Sarco DN100 TP1 temporary conical
shaped strainer having the standard 100% stainless steel
screen with 3 mm perforations, for installation between
EN 1092 PN25 flanges.
TI-P169-06 ST Issue 3
TP1, TP2, TP3 and Spacer Ring Stainless Steel Temporary Strainers
7.7.2
