Dimensions/weights (approximate) in mm and kg
Flanged ASME 150
Size
A
B
C
D
E
F
Weight
DN25
127
62
162
108 101
19
2.9
DN32
140
65
182
118 106
25
3.8
DN40
165
70
186
127
118
30
5.4
DN50
178
75
186
152 123
37
7.9
DN65
190
79
278
178 144
50
12.0
DN80
203
91
417
191 157
57
15.8
DN100
229
98
517
229 172
75
24.8
DN150
267
130
700
279 205 100
43.8
Flanged ASME 300
Size
A
B
C
D
E
F
Weight
DN25
165
62
162
124
DN32
178
65
182
134
DN40
190
70
186
156
DN50
216
75
186
165
DN65
241
79
278
190
DN80
283
91
417
210
DN100
305
98
517
254
DN150
403
130
700
318
101
19
4.5
106
25
5.7
118
30
8.2
123
37
10.3
144
50
16.0
157
57
22.3
172
75
36.1
205 100
66.6
B
C
B
C
E
E
ØD
ØF
Ø
DN25 to DN50
A
A
ØF
DN65 to DN150
Kv values
DN
25
32
40
50
65
80
100
150
Kv
30
40
81
103
197
248
581
735
For conversion: Cv (UK) = Kv x 0.963
Cv (US) = Kv x 1.156
Operating torques (N m)
DN
25
32
40
50
65
80
100
150
N m
20
25
35
60
100
120
170
400
Note: The torque figures shown are for a valve that is frequently operated at the maximum operating pressure. Valves that are subject
to long static periods, may require a greater break-out torque.
Safety information, installation and maintenance
For full details see the Installation and Maintenance Instructions supplied with the product.
How to order
Specify
Body material
2 = Zinc plated carbon steel
3 = Stainless steel
Example: 1 off Spirax Sarco DN50 M40Hi2 ISO ball valve having flanged ASME 150 connections.
Optional extras:
-
Self-venting ball.
-
Extended stems to allow full insulation: 50 mm (2") for the DN25 to DN50 and 100 mm (4") for the DN25 to DN150.
-
Lockable handle.
-
100 mm extended stem with lockable handle.
M40HTi ISO (Tobacco)
TI-P133-88 ST Issue 2
Reduced Bore Ball Valve DN25 to DN150 Flanged ASME 150 and ASME 300
