Pipeline ancillaries
HVB3aslltvoaplveaslve
Dimensions/weights (approximate) in mm and kg
Flanged ANSI 150
Size
A
D
E
F
Weight
Kv values
DN
25
40
50
65
80
100
150
Kv
21
81
94
197
248
581
730
For conversion:
Cv (UK) = Kv x 0.963
Cv (US) = Kv x 1.156
DN25
DN40
DN50
DN65
DN80
DN100
DN150
127
165
178
190
203
229
267
108
127
152
178
190
229
279
20
49
31
54
36
61
50
63
57
73
75
82
100
118
2.15
4.20
6.30
Operating torques (N m)
9.50
DN
25
40
50
65
8
0
10
0
150
11.80
N m
12
18
23
40
50
65
200
19.80
The torque figures shown are for a valve at maximum operating
32.70
pressure that is operated frequently.
Valves that are subject to long static periods, may require greater
break-out torque.
Safety information, installation and maintenance
For full details see the Installation and Maintenance Instructions
supplied with the product.
F
D
ØE
How to order
Size
Specify:
Model
Seats
Material
Example: 1 off Spirax Sarco DN50 flanged ANSI 150 M40S2 ISO
Automation ball valve.
Seats
The spare parts available are shown in solid outline. Parts drawn
in broken line are not supplied as spares.
Available spare
Seat and stem seal set
How to order spares
5, 6
Body material
S =
2 =
PTFE PDR 0.8
Carbon steel
3 =
Stainless steel
A
Flanged ANSI 300
Size
A
DN25
165
DN40
190
DN50
216
DN65
241
DN80
283
DN100
305
DN150
403
D
124
156
165
191
210
254
318
E
F
20
59
31
64
36
69
50
75
57
87
75
97
100
118
Weight
Spare parts
3.91
7.46
9.26
13.16
19.47
32.24
headed 'Available spare' and state the size and type of ball valve.
Always order spares by using the description given in the column
56.70
Example: 1 - Seat and stem seal set for a Spirax Sarco DN50
M40S2 ISO Automation ball valve.
6
6
5
5
M40S ISO Automation Ball Valve DN25 to DN150
