Dimensions / weights (approximate) in mm and kg
Flanged ASME (ANSI) 150
Size
A
B
C
D
E
F
Weight
DN50
178
275
140
DN65
190
415
160
DN80
203
515
168
DN100
229
700
202
DN150
394
850
283
DN200
457
950
317
152
50
70
10.8
178
63
82.5
16.2
191
74
87
20.0
229
100
106
35.3
279
150
197
80.2
343
201
228
140.0
Flanged ASME (ANSI) 300
Size
A
B
C
D
E
F
Weight
DN50
216
DN65
241
DN80
283
DN100
305
DN150
403
DN200
502
C
275
140
165
415
160
191
515
168
210
700
202
254
850
283
318
950
317
381
B
F
50
85.5
14.8
63
90.5
22.8
74
99
30.0
100
122
50.0
150
179
111.2
201
213
185.3
ØE ØD
A
Kv values
DN
50
65
80
100
150
200
Kv
300
430
750
1030
2410
4800
For conversion: Cv (UK) = Kv x 0.963 Cv (US) = Kv x 1.156
Operating torque (N m)
DN
50
65
80
100
150
200
N m
75
120
190
250
The torque figures shown are for a valve at maximum operating pressure that is operated frequently.
Valves that are subject to long static periods, may require greater break-out torque.
Safety information, installation and maintenance
For full details see the Installation and Maintenance Instructions supplied with the product.
720
1150
How to order
Size
Model
Specify:
Body material
Flanges
Example: 1 off Spirax Sarco DN50 flanged ASME 150 M33V2 ISO ball valve.
DN50, DN65, DN80, DN100, DN150, DN200
M33V_ISO
2 = Carbon steel
3 = Stainless steel
ASME 150 or ASME 300
M33V ISO Full Bore Ball Valve API 6D DN50 to DN200 ASME (ANSI) 150 and 300
