Technical data

Leakage test procedure to ISO 5208 (Rate A) / EN 12266-1 (Rate A)

Materials comply with;

Stem seal and seat

Flow characteristic

Port

Kv values

-

FDA CFR title 21 part 177, section 1550.

-

USP23 Class VI

Modified linear

True port design

Size

1⁄2"

3⁄4"

1"

11⁄2"

2"

Kv

7

25

56

164

360

For conversion

Cv (UK) = Kv x 0.963

Cv (US) = Kv x 1.156

Torque value

Size

1⁄2"

3⁄4"

1"

11⁄2"

2"

Nm

13

15

19

70

100

The torque figures shown are for a valve at maximum operating pressure that is operated frequently.

Valves that are subject to long static periods, may require greater break-out torque.

Dimensions / weights (approximate) in mm and kg

Size

Weight

0.80

1.00

1.55

4.50

7.70

A1 A2

A3

B C

D

E1 E2 F

G

(Clamp)

G

(ETO)

89.0 140.0

114.5

161 92

24

25.0 12.70 9.4

44.5

70.0

101.6 152.4

127.0 161 94

26 25.0 19.05 15.8

50.8 76.2

114.2 165.0

139.6

161 101

31

50.5 25.40 22.2

57.1

82.5

139.6 190.4

165.0

185 126

48

50.5 38.10 34.8

69.8

95.2

158.7 203.1

180.9 250 141

57 64.0 50.80 47.5

79.4 101.6

1⁄2"

3⁄4"

1"

11⁄2"

2"

G

B

E2

F

C

D

E1

TI-P182-05 ST Issue 6

Page 3 of 4

A1

Sanitary clamp

A2

Tube

A3

Sanitary clamp / ETO

M70i ISO Forged Stainless Steel Ball Valve for Sanitary Applications
