Condensate pumps

Electric pumps

Nomenclature

The Spirax Sarco condensate recovery unit is described by a four

figure code with a prefix letter and a suffix letter.

Prefix letter - denotes nominal receiver size

A = 100 litres

B = 225 litres

C = 550 litres

D = 750 litres

E = 1 000 litres

Two numbers indicate size of motor e.g.

07 = 0.75 kW

22 = 2.2 kW

Suffix letter indicates number of pumps e.g.

S = Single pump

C = Duplicate pumps with cascade control

Example: E40C is therefore a unit with 1000 litre receiver and

duplicate pumps, each with 4.0 kW motor.

Sizing

See TI-P089-05 and TI-P089-06

Information required for quotation or with order

Drain

1" BSP

Vent A - A

Inlet

A - A

Inlet

A - A

1.

2.

3.

4.

5.

Averagerateatwhichcondensatereturnstothereceiverinkg/h

or lb/h.

Maximum temperature of condensate.

Total pumping delivery head, including static and friction loss in

pipe and fittings. In calculating the pipe friction, it must be

remembered that the pumping rate is approximately 1.1 times the

rate which the condensate returns to the receiver in the case of a

cascade unit and 1.5 times in the case of a unit with single pump.

Electric supply available and voltage.

Any abnormal operating conditions which may be encountered.

Overflow A - A

Fixing holes 19 mm dia.

Discharge

B- B

Connections

Pump and motor details, connections and weights

Motor

Unit

kW

A0207 0.75

A2107 0.75

A2111 1.10

A0507 0.75

B5511 1.10

B0507 0.75

B0611 1.10

B0615 1.50

B0622 2.20

B5830 3.00

B5840 4.00

C5511 1.10

C0615 1.50

C0622 2.20

Connections

Weight

Weight

A - A

11⁄2

11⁄2

11⁄2

11⁄2

2

2

2

2

2

2

2

21⁄2

21⁄2

21⁄2

BSP

Single

Cascade

B - B

pump

pumps

1

125 kg

145 kg

1

130 kg

150 kg

1

135 kg

155 kg

11⁄2

140 kg

160 kg

11⁄2

155 kg

190 kg

11⁄2

155 kg

190 kg

11⁄2

205 kg

275 kg

11⁄2

215 kg

285 kg

11⁄2

255 kg

295 kg

11⁄2

260 kg

360 kg

11⁄2

280 kg

385 kg

11⁄2

240 kg

270 kg

11⁄2

290 kg

400 kg

11⁄2

300 kg

410 kg

Motor

Unit

kW

C5830

3.0

C5840

4.0

C5930

3.0

C5940

4.0

C5955

5.5

D5822

2.2

D5830

3.0

D5840

4.0

D5930

3.0

D5940

4.0

D5955

5.5

E5930

3.0

E5940

4.0

E5955

5.5

A - A

21⁄2

21⁄2

21⁄2

21⁄2

21⁄2

3

3

3

3

3

3

4

4

4

BSP

B - B

11⁄2

11⁄2

2

2

2

11⁄2

11⁄2

11⁄2

2

2

2

2

2

2

Single

pump

290 kg

300 kg

320 kg

330 kg

350 kg

330 kg

340 kg

350 kg

354 kg

364 kg

383 kg

390 kg

400 kg

420 kg

Cascade

pumps

390 kg

400 kg

450 kg

460 kg

485 kg

435 kg

445 kg

455 kg

473 kg

483 kg

500 kg

530 kg

540 kg

560 kg
