Steam traps

Swivel connectors and traps

Local regulations may restrict the use of this product to below the conditions quoted.

In the interests of development and improvement of the product, we reserve the right to change the specification without notice.

TI-P128-02

ST Issue 8

PC3_

Pipeline Connectors

Description

The PC3_ range of pipeline connectors have been designed for

use with swivel connector steam traps. The PC3_ is a pipeline

connector with one integral stop valve which isolates upstream of

the steam trap. The stop valve is a piston type. The PC3_ is

available with optional connections (BDV1 and / or BDV2) for the

draining of upstream pipework and trap venting upstream of the

steam trap - See 'Optional extras'.

Optional extras (see TI-P600-01 for further details)

BDV1 blowdown valve is available for the draining of upstream

pipework during operation. Care should be taken when using the

BDV1 blowdown valve as the discharge may be hot.

BDV2 depressurisation valve is available to provide side

connection discharge, generally to be used as a vent for top pipe

mounting or for line depressurisation, to ensure discharge is piped

to grade/atmosphere.

Standards

These products fully comply with the requirements of the

European Pressure Equipment Directive 97 / 23 / EC.

Certification

These products are available with certification to EN 10204 3.1.

Note: All certification/inspection requirements must be stated

at the time of order placement. For other certification contact

Spirax Sarco.

Sizes and pipe connections

DN15 and DN20 condensate inlet/outlet connections are

available in screwed BSP or NPT and socket weld ends to

ASME B16.11 class 3000. Drainage and venting connections are

available in DN15 screwed BSP or NPT and socket weld

connections for use with BDV1 or BDV2 valves.

Flanged versions are also available upon request. Please contact

Spirax Sarco for further details.

Pressure/temperature limits

��

Pressure bar g

Available types

For piping installation diagrams see TI-F01-37.

Flow direction

Left to right

Right to left

Universal -

Both:

left to right

right to left

11 12

Description

1 stop valve +

upstream line drain for a BDV1 or BDV2

and trap vent connection for BDV2

1 stop valve

1 stop valve +

upstream line drain connection either

side of the body for BDV1 or BDV2.

It is necessary to plug one connection.

This must always be the top connection.

PC30 shown

View showing valve internals

3 4 2 5

Material

Austenitic stainless steel ASTM A182 F304 / 304L

Graphite and stainless steel

Notes:

1. If flange connections are fitted then these will limit the maximum

Materials

No. Part

1 Body

2 Lower ring

3 Upper ring

4 Lantern bush

5 Piston

6 Spindle

7 Handwheel

8 Handwheel nut

9 Bonnet

10 Studs

11 Nuts

12 Washers

13 Washer

14 Name-plate

design conditions of the pipeline connector.

2. The maximum operating limits of the complete assembly will be

dictated by the steam trap of choice. Reference the specific steam

trap technical information sheet for its 'Pressure / temperature limits'.

Steel

Stainless steel

Steel

Carbon steel

Stainless steel and nylon insert

Carbon steel

Steel (ENP)

Steel

Stainless steel

Body design conditions

PMA Maximum allowable pressure

TMA Maximum allowable temperature

PMO

Maximum operating pressure

for saturated steam service

TMO Maximum operating temperature

ASME class 600

99.3 bar g @ 38°C

425°C @ 56 bar g

62 bar g

UNI 4838 CF95 SMn Pb36

ASTM A479 F316

ASTM A479 F410

ASTM A105N

425°C @ 56 bar g

Designed for a maximum cold hydraulic test pressure of 150 bar g

ASTM A105N

ASTM A193-B7

ASTM A194-2H

Kv value:

Both the DN15 and DN20 have a Kv value of Kv 1.8

For conversion: Cv (UK) = Kv x 0.963

Cv (US) = Kv x 1.156
