Basic dimensions

PelTec 12

PelTec

Heat output

Heat output range

Flue gas tube - outer diameter *

Main flow / Return flow

Filling / Draining

Max. operating temperature

Boiler water content

Max. operating overpressure

Pellet tank volume

Total depth (A)

Total width (B)

Total height (C)

Depth for entering the boiler room

Width for entering the boiler room

Height for entering the boiler room

Boiler mass

Energy efficiency class

PelTec 18

PelTec 24-48

12

18

12

18

3,6-12

5,4-18

130

130

1"

1"

1/2"

1/2"

90

90

78

76

2,5

2,5

340

340

1105

1105

1200

1420

1560

1560

760

760

650

880

1560

1275

328

349

A+

A+

1

Boiler controller

2

Flue gas fan

3

Pellet tank

4

Pellet level sensor in the tank

5

Screw transporter

6

Pump group with pump

and 4-way mixing valve with

actuator

(kW)

(kW)

Ø (mm)

(R)

(R)

(°C)

(lit.)

(bar)

(lit.)

(mm.)

(mm.)

(mm.)

(mm.)

(mm.)

(mm.)

(kg)

24

36

24

36

7,2-24

10,8-36

130

150

5/4"

5/4"

1/2"

1/2"

90

90

100

108

2,5

2,5

340

340

1080

1160

1420

1485

1560

1560

760

840

855

945

1340

1340

402

455

A+

A+

48

48

14,4-48

150

5/4"

1/2"

90

135

2,5

340

1175

1485

1560

840

945

1490

478

A+

* The inner diameter of the chimney is determined according to the power of the boiler and the height of the chimney and must almost always be larger than the diameter of the flue gas tube

PELTEC 12-48 kW
