Basic dimensions
1
2
3
4
5
6
7
7a
8
Boiler body with burner with movable grate
and thermal insulation
Supply screw transporter with supply
transporter connection 2, back flame
protection and backfill sensor
Boiler thermal protection connections
Cyclone with ash box (possible installation
on the left or right side)
Cyclone fan
Automatic ash extraction system with ash
containers (screw)
Electrical cabinet with digital boiler
controller
Controller
Automatic flue pipe cleaning system -
pneumatic (accessories)
580
580
174 - 580
100
EKO-CKS MULTI PLUS 170-580 kW
EKO-CKS Multi Plus
170
250
340
450
Rated heat output
Power range
Main flow / return flow
Max. operating temperature
Max. operating overpressure
Total boiler depth A
Total boiler width B
Total boiler height C
Energy efficiency class
(kW)
170
(kW)
51 - 170
(R)/(DN)
2"
250
75 - 250
80
340
450
102-340
135 - 450
80
100
(°C)
95
95
95
95
95
(bar)
4
4
4
4
4
(mm)
3885
(mm)
2010
(mm)
2270
3885
4235
4720
4720
2170
2260
2555
2655
2520
2520
2595
2775
A+
A+
A+
A+
A+
