Equipment HeatBloC® MCom DN 25 up to DN 50

Wall bracket for HeatBloC® DN 40 (1

1⁄2")

Components: Wall bracket, 2 gaskets, mounting equipment,

distance of the pipe axis to the wall A = 270 mm

41641

Wall bracket for HeatBloC®s - DN 50 (2")

Components: Wall bracket (galvanised steel), 2 gaskets, mounting equipment,

distance of the pipe axis to the wall A = 400 mm

41642

Wall bracket set for modular distribution manifold - DN 40 (1

1⁄2")

Components: 2 floor brackets (galvanized steel), 8 wall plugs, 8 screws, 2 screws for fixing

the distribution manifold onto the floor brackets

Distance of the pipe axis to the wall: A = 400 mm

41651

Wall bracket set for modular distribution manifold - DN 50 (2")

Components: 2 floor brackets (galvanized steel), 8 wall plugs, 8 screws, 2 screws for fixing

the distribution manifold onto the floor brackets

Distance of the pipe axis to the wall: A = 400 mm

41652

Floor bracket set for modular distribution manifold - DN 40 / 50 (11⁄2"/ 2")

Components: 2 floor brackets (galvanized steel), 4 wall plugs, 4 screws, 2 screws for fixing

the distribution manifold onto the floor brackets

Height = adjustable 1,050 - 1,080 mm, for shortening simply cut off

41671

Extension set HeatBloC® MCom - DN 25 / 32

Required extension set for operating MCom heating circuits DN 25/32 when used in

building cooling and heating.

With the extension set, the thermal separation of electronic components is achieved in

order to avoid damage caused by condensate. The thermometers are replaced by

condensate-proof thermometers.

4537023

Extension set HeatBloC® MCom - DN 40 / 50

Required extension set for operating MCom heating circuits DN 40/50 when used in

building cooling and heating.

With the extension set, the thermal separation of electronic components is achieved in

order to avoid damage caused by condensate. The thermometers are replaced by

condensate-proof thermometers.

4546021
