Mounting equipment solar DN 25

M

o

u

n

t

i

n

g

e

q

u

i

p

m

e

n

t

s

o

l

a

r

D

N

2

5

Hand filling pump

1⁄2" external thread, 15 mm hose connection, attainable pressure up to approx. 4 bar,

length 225 mm

Hand filling pump with fill and drain valve

1⁄2" external thread, 15 mm hose connection, attainable pressure up to approx. 4 bar,

length 225 mm

7061

7062

Hose connector for hand filling and injection pump

Hose connector for hand filling and injection pump

1⁄2" x 15 mm

70611

Flush and fill unit DN 25 (1") for 22 mm copper pipe

consisting of: Brass ball valve internal thread 1", with red butterfly handle, with 2 outlets

1⁄2" before and after the ball, 2 self-sealing fill and drain valves with hose connector 15

mm

56431 and 56451: additionally with 2 cutting-ring compression fittings with support

sleeve, premounted

56451

Flush and drain unit DN 25 (1")

Counter T-piece with self-sealing fill and drain valve.For extending the solar station with

a flush and drain connection or for installation at the lowest point (drain unit).

34611

Cutting-ring compression fitting DN 25 (1"), d = 22 mm

1" external thread, self-sealing with o-ring, with support sleeve, suitable for soft copper

pipes. For temperatures up to 150 °C.

562922

Immersion sleeve

1⁄2" ext. thread x T = 150 mm

standard, chromed copper, for sensor, T = 150 mm

For all immersion sleeves: for the installation of the temperature sensors (d = 6 mm) in

the storage tank, in the collector and the hydraulic separator.

Attention: suitable for ball valves until 2016!

566004

Flush and fill unit DN 25 (1")

Flush and fill unit DN 25 (1") for 15 mm copper pipe

5640

56431

Cutting-ring compression fitting DN 25 (1"), d = 15 mm

Cutting-ring compression fitting DN 25 (1"), d = 18 mm

Immersion sleeve

1⁄2" ext. thread x T = 30 mm

self-sealing, with o-ring, polished brass, for sensor, T = 30 mm

Immersion sleeve

1⁄4" ext. thread x T = 60 mm

standard, chromed brass, for sensor, T = 60 mm

Immersion sleeve

1⁄2" ext. thread x T = 60 mm

standard, chromed brass, with valve extension (25 mm), for sensor, T = 60 mm

Immersion sleeve

1⁄2" ext. thread x T = 100 mm

standard, chromed copper, for sensor, T = 100 mm

562915

562918

566001

566002

5660021

566003
