HomeBloC® Basic WF
Radiant floor circuit (mixed)
Application range
Max. operating pressure
Operating temperature
Output
for residential properties with one or various radiant floor
circuits
Operating pressure: domestic hot water
Operating pressure: heating system
Operating temperature: heating system
Operating temperature:
Technical data
Connections
Domestic hot water supply
Heat supply
Heating circuit outlets
Materials
Cover frame, door, base cover
Ball valves, valves and fittings:
Domestic hot water circuit
Ball valves, valves and fittings:
Heating circuit
Pipes
Gaskets
3 x
3⁄4" int. thread (flat-sealing and
self-sealing)
2 x
3⁄4" int. thread (flat-sealing and
self-sealing)
2 x
3⁄4" int. thread (flat-sealing and
self-sealing)
Steel sheets, powder-coated, white
(RAL 9016)
Brass, approved for potable water
Brass, approved for potable water
Stainless steel (1.4401), approved
for potable water
Fibre composite / EPDM / Teflon
domestic hot water
Output capacity (10 ->45°C)
Heating capacity
Dimensions
Base plate station
Flush-mounted cupboard
Cover frame (flush-mounted
cupboard)
Wall-mounted cupboard
Adjustment range of the base
max. 10 bar
max. 2.5 bar
max. 85 °C
max. 65 °C
12 l/min (≙ 30 kW);
16 l/min (≙ 40 kW);
20 l/min (≙ 49 kW)
8.5 kW
(when ΔT = 15 K)
W = 660 mm, H = 555 mm,
D = 100 mm
W = 750 mm, H = 685 mm,
D = 10 mm
W = 750 mm, H = 555 mm,
D = 110 mm
W = 750 mm, H = 555 mm,
D = 150 mm
0 - 80 mm
Base plate / Flush-mounted
cupboard
zinc-galvanised steel sheet
Total dimensions cupboard for
station + floor distribution
manifold
W = 750 mm, H = 1,436 mm
Heat exchanger
Standard: Copper solder; Stainless
steel plates
more heat exchanger designs: see
order table
PAW-HomeBloC® Basic WF - Radiant floor circuit (mixed)
Heat exchanger
24 plates, copper solder
24 plates, coated
32 plates, copper solder
32 plates, coated
50 plates, copper solder
50 plates, full stainless steel
Injection-type circuit for the radiant floor circuit
Volume flow limiter*
12 l/min
12 l/min
16 l/min
16 l/min
20 l/min
20 l/min
Item no.
120319101
120349101
120429101
120459101
120539101
120569101
Connections: 2x 1"int. thread x 2x 3⁄4"ext.thread, GF UPM3 Auto L 15-70, mandatory for floor distribution manifold
