Pipe set for FriwaMidi-Kaskade

Insulated pipe set for cascading of two Friwa modules (item no. 6405511)

- with 2 two-way valves for switching

- with mounting rail for an easy wall assembly

64042943

Pipe set for FriwaMaxi-Kaskade

Insulated pipe set for cascading of two Friwa modules (item no. 6406511)

- with 2 two-way valves for switching

- with mounting rail for an easy wall assembly

64042953

Pipe set for FriwaMega-Kaskade

Insulated pipe set for cascading of two Friwa modules (item no. 6407511)

- with two 2-way valves for switching

64042963

WiFi3.10 Internet Gateway Module

Communication module to connect PAW systems with domestic hot water controllers

FC3.10 or solar controllers SC3.10 with the Internet visualisation platform emodul.eu.

The communication module WiFi3.10 is connected to the FC3.10 or SC3.10 master via the

integrated RS interface. The system specific data points are transmitted wirelessly to the

platform emodul.eu via a router provided by the customer. An Internet access is

required. Exclusive integration into the network structure provided by the customer.

Consists of controller WiFi3.10, power supply unit, RS bus cable, instructions

Operating voltage: 115-230 V/50-60 Hz

Protection type: IP 20

1339003

MB3.10

Communication module to integrate PAW systems with domestic hot water controllers

FC3.10 or solar controllers SC3.10 into superior systems with Modbus RTU interface.

The communication module consists of two separate Modbus interfaces. The RS485

interface is connected with the master controller FC3.10 or SC3.10 of the PAW system.

The communication module provides the superior Modbus server with the data via the

Modbus RTU interface. All inputs and outputs of the connected controllers are available

as readable data points.

1339002

2-way zone valve - DN 25 (1") for tank heat transfer module Midi

for connecting and disconnecting single storage tanks,

DN 25, 1" int. thread, setting time for 90°: 30 sec., Kvs value = 68

563542

2-way zone valve - DN 32 (11⁄4") for tank heat transfer module Maxi

for connecting and disconnecting single storage tanks,

DN 32, 1

1⁄4" internal thread, setting time for 90°: 30 sec., Kvs value = 123

563552
