Check valves

Check valve SBA - DN 25 (1")

Check valve SBM - DN 20 (3⁄4")

Check valve SBM with automatic air passage - DN 20 (

3⁄4")

Check valve SBM - DN 25 (1")

Check valve SBM with automatic air passage - DN 25 (1")

Check valve SBM - DN 32 (11⁄4")

Check valve SBE - int. thread DN 20 (

3⁄4")

Check valve SBE - int. thread DN 25 (1")

Check valve SBE with automatic air passage - int. thread DN 25

(1")

Check valve SBE - ext. thread DN 25 (1")

01/2024 • Printed in Germany

PAW GmbH & Co. KG • info@paw.eu • www.paw.eu

Connection

ext.: 1

1⁄2"

Flange (w/ nut): 1"

int.: 1" ext.: 1"

int.: 1

1⁄4" ext.: 11⁄4"

int.: 1" ext.: 1"

int.: 1

1⁄2" ext.: 11⁄2"

int.: 1

1⁄2" ext.: 11⁄2"

int.: 1

1⁄2" ext.: 11⁄2"

int.: 1

1⁄2" ext.: 11⁄2"

int.: 2" ext.: 2"

int.:

3⁄4"

Flange: 1"

int.: 1"

Flange: 1"

int.: 1"

Flange: 1"

int.: 1"

Flange: 1"

ext.: 1"

Flange: 1"

Length

48 mm (IL)

26 mm (IL)

28 mm (IL)

26 mm (IL)

28 mm (IL)

37 mm (IL)

28 mm (IL)

37 mm (IL)

38 mm (IL)

41 mm

45 mm

57 mm

45 mm

57 mm

Item no.

1003

1016

1015

1116

1055

1005

1155

1105

1006

1019

1017

1007

1117

1010

Check valve SBA with automatic air passage - DN 25 (1")

Check valve, can be opened, with union nut, gasket and PAW flange

for warm water central heating, PN 10, 120 °C, suited for horizontal

and vertical installation, to be screwed directly on the pump.

Opening pressure 200 mm wc

IL = Installation length

ext.: 1

1⁄2"

Flange (w/ nut): 1"

24 mm (IL)

1103

Check valve SBM with automatic air passage - DN 32 (11⁄4")

Check valve, can be opened, with gasket for warm water central

heating, PN 10, 120 °C, suited for horizontal and vertical installation,

to be screwed directly to the pump.

Opening pressure 200 mm wc

IL = Installation length

int.: 2" ext.: 2"

38 mm (IL)

1106

Check valve SBE with automatic air passage - int. thread DN 25

(1")

Check valve, can be opened, with automatic air passage, with internal

thread and PAW flange for warm water central heating, PN 10, 120 °C.

Suited for horizontal and vertical installation. Can also be used as non

return valve. To be directly screwed to the pump.

Opening pressure 200 mm wc

int.: 1"

Flange: 1"

57 mm

1107

Check valve SBE with automatic air passage - ext. thread DN 25

(1")

Check valve, can be opened, with automatic air passage, with external

thread and PAW flange for warm water central heating, PN 10, 120 °C.

Suited for horizontal and vertical installation. Can also be used as non

return valve. To be directly screwed to the pump.

Opening pressure 200 mm wc

ext.: 1"

Flange: 1"

57 mm

1110
