Thread connection for PAW flange DN 32 (11⁄4")

Thread connection for PAW flange with union nut, screw-in fitting and gasket

2152

Pump fitting DN 20 (

3⁄4")

with union nut, insert fitting and gasket, length: 30 mm

2049

Pump fitting 25 (1")

with union nut, insert fitting and gasket, length: 28 mm

2149

Pump fitting DN 32 (1

1⁄4")

with union nut, insert fitting and gasket, length: 31 mm

2150

Screw-in fitting DN 20 (

3⁄4")

1" external thread, flat-sealing x 3⁄4" internal thread

2053

Screw-in fitting 25 (1")

1

1⁄2" external thread, flat-sealing x 1" internal thread

2153

Screw-in fitting DN 32 (1

1⁄4")

2" external thread flat-sealing x 1

1⁄4" internal thread

2154

Insert fitting - DN 32 (1

1⁄4")

For the connection of pipes with external thread

2160

Union nut DN 20 (

3⁄4")

Brass, to screw insertion pieces for soldering below distribution manifolds DN 20 (

3⁄4")

2055

Union nut DN 25 (1'')

Brass, to screw insertion pieces for soldering below distribution manifolds DN 25 (1")

2155

Union nut DN 32 (1

1⁄4'')

Brass, to screw insertion pieces for soldering below distribution manifolds DN 32 (1

1⁄4")

2156

Sealing for nut - DN 20 (

3⁄4")

asbestos-free, outside diameter: 30 mm, inside diameter: 21 mm, height: 2 mm

2057

Sealing for nut - DN 25 (1")

asbestos-free, outside diameter: 44 mm, inside diameter: 32 mm, height: 2 mm

2157

Sealing for nut - DN 32 (1

1⁄4")

asbestos-free, outside diameter: 50 mm, inside diameter: 38 mm, height: 2 mm

2158

Thread connection for PAW flange DN 20 (

3⁄4")

Thread connection for PAW flange DN 25 (1")

2051

2151

202

01/2024 • Printed in Germany

PAW GmbH & Co. KG • info@paw.eu • www.paw.eu

Insert fitting DN 25 (1")

2159
