Equipment for modular sytem DN 32
Fitting for heat flowmeter - DN 32 for unmixed HeatBloC®s
- for unmixed HeatBloC®s DN 32
- for heat flowmeters with the dimensions
3⁄4" x 110 mm and 1" x 130 mm
Scope of delivery:
- Pump ball valve with check valve, can be opened (200 mm wc)
- Screw-in fittings, flat sealing
- Union nut
- Adapter pipe
- Reducers for immersion sensor (1⁄4" ext. thread, self-sealing x M10 x 1" int. thread and
1⁄4" ext. thread, self-sealing x M12 x 1.5" ext. thread)
- Seals
37453
Fitting for heat flowmeter - DN 32 for mixed HeatBloC®s
- for HeatBloC®s DN 32 with 3-way or 4-wax mixing valve
- for heat flowmeters with the dimensions 1" ext. thread x 130 mm
Scope of delivery:
- Screw-in fittings flat sealing
- Adapter pipe
- Reducers for immersion sensor (1⁄4" ext. thread, self-sealing x M10 x 1" int. thread and
1⁄4" ext. thread, self-sealing x M12 x 1.5" ext. thread)
- Non-return valve for mixing valve return
- Seals
37463
Immersion sleeve
1⁄2" ext. thread x T = 150 mm
standard, chromed copper, for sensor, T = 150 mm
For all immersion sleeves: for the installation of the temperature sensors (d = 6 mm) in
the storage tank, in the collector and the hydraulic separator.
Attention: suitable for ball valves until 2016!
566004
Adapter pipe DN 32 (11⁄4")
Brass, 2 x 2" external thread, flat-sealing, length 180 mm, when an external circulation
pump is used to bridge the pump connection.
3747
Flush and drain set DN 32 (
1⁄4")
2 x counter-T-pieces 1
1⁄4" with fill and drain valve, each equipped with an extension
piece, permits to flush and drain individual HeatBloC®s.
Careful: Flush and drain set is not compatible with the HeatBloC® MC system!
3761
Union nut DN 32 (1
1⁄4'')
Brass, to screw insertion pieces for soldering below distribution manifolds DN 32 (1
1⁄4")
2156
Immersion sleeve
1⁄2" ext. thread x T = 30 mm
self-sealing, with o-ring, polished brass, for sensor, T = 30 mm
Immersion sleeve
1⁄4" ext. thread x T = 60 mm
standard, chromed brass, for sensor, T = 60 mm
Immersion sleeve
1⁄2" ext. thread x T = 60 mm
standard, chromed brass, with valve extension (25 mm), for sensor, T = 60 mm
Immersion sleeve
1⁄2" ext. thread x T = 100 mm
standard, chromed copper, for sensor, T = 100 mm
