RILEVAZIONE GAS DOMESTICA

RESIDENTIAL GAS DETECTION

Modello

Type

Gas rilevato

Detected gas

Uscite

Outputs

Portata

Capacity

Taratura

Calibration

Durata media sensore

Sensor life

Stoccaggio

Storage time

SE230KM

SE230KG

Metano - Methane

GPL - LPG

N°1 Relè / Relay

Buzzer 85dB (A) 1 m

Logica negativa

Negative logical

3(1)A 250Vac

2A 24Vcc.

BO205

5 anni - 5 years

5 anni - 5 years

SE233KM

SE233KG

Metano - Methane

GPL - LPG

N°1 Relè / Relay

Buzzer 85dB (A) 1 m

Logica positiva

Positive logical

3(1)A 250Vac

2A 24Vcc.

BO205

5 anni - 5 years

5 anni - 5 years

SE296KM

SE296KG

Metano - Methane

GPL - LPG

Buzzer 85dB (A) 1 m

NO

BO205

5 anni - 5 years

5 anni - 5 years

69

Rivelatori di gas Metano e GPL con allarme acustico e relé

Natural gas and LPG detector with acoustic alarm and output relay

IP42

Certificato alle norme: EN 50194

Standards certified: EN 50194

GAMMA SE230K

SE296K

La certificazione IMQ secondo la norma CEI EN 50194, garantisce la perfetta funzionalità

di questi rivelatori di gas.

In presenza di concentrazioni di gas, la spia di allarme si illumina, il buzzer emette

un forte suono e grazie al relè di cui sono dotati è possibile comandare la chiusura

dell’elettrovalvola di intercettazione gas.

The IMQ certification in accordance to the standards CEI EN50194 gurantees the

perfect working of these gas detectors.

In presence of gas concentration, the alarm spy is lighting, the buzzer emits a loud

signal and thanks to the output relay, it is possible to manage the closing of the solenoid

gas valve.

Alimentazione: 230 Vca (±10%) e 12Vdc

Power supply: 230 Vac (±10%) e 12Vdc

Assorbimento: 4VA a 230Vca

Absorption: 4VA (230Vca)

Sensore: Catalitico

Sensor: Catalytic

Soglia di allarme: 10% L.I.E. - Campo di misura: 0÷20% LIE

Alarm level: 10% L.E.L. - Measuring range: 0÷20% LEL

Relè di uscita: in scambio 3A 250Vac

Output relay: exchange contacts 3A 250Vac

Sensore ausiliario

Auxiliary Sensor

SE296K

Sensore ausiliario di gas metano o GPL per centraline modello SE230/233 KM/KG con

segnalazione ottico (LED) acustica (cicalino) della presenza di gas in ambiente.

Il prodotto è completo di segnalazione presenza rete (led verde) e di sensore non

funzionante “Fault” (led giallo).

È possible collegare più dispositivi tra loro e comandare una sola elettrovalvola.

Auxiliary methane or LPG sensor for central units type SE230/233 KM/KG with optical

(LED) and acoustic (buzzer) signallers for presence of gas in environment.

This article is equipped with network power signalling device (green LED lamp) and out-

of-work - “FAULT” sensor (yellow LED lamp).

It is possible to connect more sensors together and to manage only one electrovalve.
