METALLIC FIXINGS
FIXATIONS METALLIQUES
FM-753 3DG
Heavy duty through anchor
Goujon d’ancrage lourd traversant
1
2
1
2
3
4
3
4
CERTIFICATIONS
CERTIFICATIONS
Non-cracked concrete
Béton non fissuré
Assembled
stainless steel A4 clip
Special anti-corrosion coating
with matte finish
Monté
bague acier inoxydable A4
Revêtement spécial anti-corrosion
avec finition mate
Dimension
Ø x L
M6x45
M6x65
M6x85
M6x100
M8x50
M8x65
M8x75
M8x90
M8x115
M8x135
M8x165
M10x60
M10x75
M10x90
M10x100
M10x120
M10x145
M10x170
M10x210
M12x80
M12x100
M12x110
M12x135
M12x160
M12x185
M12x200
M12x220
M12x240
M12x255
M12x285
M12x300
M12x325
M16x110
M16x125
M16x145
M16x175
M16x215
M16x230
M16x250
M16x270
M16x320
M20x170
M20x215
M20X280
Fixing thickness / Épaiss. à fixer
