URINALS /

SIPHONIC URINAL GOLEM ANTIVANDAL WITH RADAR SENSOR

POWERED 24V DC

Article number

H8430700004831

Description

Golem Antivandal urinal, power suply 24 V DC,

with inner water inlet, including installation kit

and siphon 1 l

55

This product includes radar circuitry attached to a mounting rail - 24V

power supply, a solenoid valve, connecting hoses, an angle valve

with filter and non-return valve, an inlet valve with gaskets, a siphon,

a mounting kit and a assembly template.

Optional:

H8940770000001

H8950910000001

H8950710000001

H8950720000001

H8910620000001

Spare parts:

H8430700000001

H8950740000001

H8903490008901

H8903490008911

H8920030000001

Description

remote control for sensor-controlled flushing

devices

power supply for one Golem/Livo Antivandal/

Domino Sensor urinal 24 V, DC

power supply for up to five Golem/Livo

Antivandal/Domino Sensor urinal 24 V, DC

power supply for up to nine Golem/Livo

Antivandal/Domino Sensor urinal 24 V, DC

Golem urinal strainer

Description

Golem Antivandal vacuum-system urinal,

ceramics, internal water inlet

Golem Antivandal radar sensor, mains power

supply

installation kit with white covers, 1 pair

installation kit with chrome-plated covers, 1 pair

siphon, horizontal/vertical outlet

9

1-

2 -

8

3-

4 -

5 -

6 -

7 -

8 -

9 -

water supply

electromagnetic valve

ceramic urinal

electronics with a radar

sensor for a 24 V power

supply

siphon

drain pipe,

Ø 50 mm

interconnecting hoses

a 24 V supply cable

corner valve for the

water supply

H891062

RECOMMENDED TO BE

COMBINED WITH SUITABLE

CONCEALED MODULE

FOR URINALS

PAGE 133

GOLEM ANTIVANDAL SIPHONIC URINAL WITH RADAR SENSOR AND INTEGRATED POWER SUPPLY

MAINS-POWERED

Article number

Description

H8430700004901 „Golem ANTIVANDAL urinal, power supply 24V,

with inner water inlet, including installation kit

and siphon 1 l, with power supply 230V AC“

This product includes radar circuitry attached to a mounting rail - 24V

power supply, a solenoid valve, connecting hoses, an angle valve

with filter and non-return valve, an inlet valve with gaskets, a siphon,

a mounting kit and a assembly template.

55

230V/50 Hz

Optional:

H8940770000001

H8910620000001

Spare parts:

H8430700000001

H8910740000001

H8903490008901

H8903490008911

H8920030000001

Description

remote control for sensor-controlled flushing

devices

Golem urinal strainer

Description

Golem Antivandal vacuum-system urinal,

ceramics, internal water inlet

radar sensor for Golem ANTIVANDAL, with power

supply 230V AC, mains power supply

installation kit with white covers, 1 pair

installation kit with chrome-plated covers, 1 pair

siphon, horizontal/vertical outlet

1-

2 -

8

3-

4 -

5 -

6 -

7 -

8 -

9 -

10 -

water supply

electromagnetic valve

ceramic urinal

electronics with

a radar sensor for

a 230V power supply

siphon

drain pipe,

∅ 50 mm

interconnecting hoses

a 230V supply cable

corner valve for the

water supply

power supply 230V AC

P

R

O

J

E

C

T

A

N

D

O

T

H

E

R

P

R

O

D

U

C

T

S

6

0

6

0

RECOMMENDED TO BE

COMBINED WITH SUITABLE

CONCEALED MODULE

FOR URINALS

PAGE 133
