Single phase

MPP voltage range / rated input voltage

40 V to 530 V / 380 V

SCHEDE TECNICHE - INVERTER

Inverter ibridi monofase | SOLPLANET da 3kW a 6kW

Min. input voltage / start voltage

No. of independent MPPT trackers / strings per MPPT in

Max. input current per MPP tracker

Max. short-circuit current per MPP tracker

Nominal battery voltage

Battery voltage range

Max. charging / discharging power

Max. charging current / Max. discharging current

Battery type

Compatible Battery

hybrid inverters

AC voltage range / Nominal AC voltage

Rated AC grid frequency

A

C

g

r

i

d

f

r

e

q

u

e

n

c

y

r

a

n

g

e

180 V to 280 V / 230 V

50 Hz / 60 Hz

5

0

H

z

±

5

H

z

/

6

0

H

z

±

5

H

z

25

solplanet.net

@Solplanet

● Standard features / ○ optional features / – not available

*1 For VDE-AR-N4105,Smax=Sn=4600VA,Pn=4600W *2 For AS/NZS4777.2,Iac max=21.7A

*

3

Including but not limited to the listed models, please check the website@solplanet for more compatible models

Version: July 2022

B

a

t

t

e

r

y

i

n

p

u

t

P

V

I

n

p

u

t

Models:

ASW3000H-S2

ASW3680H-S2

ASW4000H-S2

ASW5000H-S2

ASW6000H-S2

Easy-to-install

• Quick & easy-to-install with basic

tools

• Quick setup and commissioning

with Solplanet apps

• Compact wall mount design

Reliable

User-friendly

• Smart energy management

• UPS capability - power during

blackouts

• IP66 rated design for outdoor use

• User friendly app interface

• Online monitoring via Wi-Fi and

Solplanet apps

• Easy to connect - battery and smart

meter interfaces

Technical DataSheet

ASW3000H-S2 ASW3680H-S2 ASW4000H-S2 ASW5000H-S2 ASW6000H-S2

P

V

I

n

p

u

t

Max. PV array power

5500 Wp STC

6180 Wp STC

6500 Wp STC

7500 Wp STC

9000 Wp STC

Max. input voltage

550 V

MPP voltage range / rated input voltage

40 V to 530 V / 380 V

Min. input voltage / start voltage

40 V/ 50 V

No. of independent MPPT trackers / strings per MPPT input

2 / 1

Max. input current per MPP tracker

16 A

Max. short-circuit current per MPP tracker

20A

B

a

t

t

e

r

y

i

n

p

u

t

Nominal battery voltage

48 V/51.2V

Battery voltage range

40 V to 60 V

Max. charging / discharging power

5000 W / 5000 W

Max. charging current / Max. discharging current

100 A / 100A

Battery type

LiFePO4

Compatible Battery

Aiswei Ai-LB series

*3

put

40 V/ 50 V

2 / 1

16 A

20A

48 V/51.2V

40 V to 60 V

5000 W / 5000 W

100 A / 100A

LiFePO4

Aiswei Ai-LB series

*3

AC voltage range / Nominal AC voltage

Rated AC grid frequency

AC grid frequency range

Rated active power

Rated apparent power

Max. apparent power

Rated grid output Current (@230V)

Max. grid output current

Harmonics THDi (@ Nominal power)

Rated grid voltage

Rated grid frequency

Rated apparent power

Max. input apparent power from grid

Rated input current from grid

Max. input current from grid

Nominal output voltage

Nominal output frequency

Rated apparent power

Max. output apparent power

Peak output apparent power

Rated Current (@230V)

Max. output current

Max. switch time

Output THDi (@ Linear load)

MPPT efficiency

Euro efficiency / Max. efficiency

Max. battery to load efficiency

DC-side disconnection device

PV string- / Battery input reverse polarity protection

All-pole sensitive residual current monitoring unit

Anti-islanding protection

Ground fault protection

AC output over current / short circuit current protection

AC over voltage protection

Protection class (as per IEC 62109-1) /

overvoltage category (as per IEC 62109-1)

Power factor at rated power / adjustable displacement

Dimensions (W / H / D)

Device weight

Operating temperature range

Noise emissions (typical)

Standby consumption

Cooling concept

Degree of protection (as per IEC 60529)

Climatic category (according to IEC 60721-3-4)

Max. permissible value for relative humidity (non-condensing)

Max. operating altitude

Country of manufacture

User interface

Communication with BMS

Communication with meter

Communication with portal

Other communication

Integrated power control / Zero export control

3000 W

3000 VA

3000 VA

13.1 A

13.6 A

3680 W

3680 VA

3680 VA

16 A

16 A

180 V to 280 V / 230 V

50 Hz / 60 Hz

50 Hz±5Hz / 60 Hz±5Hz

4000 W

4000 VA

4000 VA

17.4 A

18.2 A

< 3%

a.c. 230V

50Hz / 60Hz

6000 VA

6000 VA

a.c. 26.1A

a.c. 27.3 A

230 V

50 Hz / 60 Hz

5000 VA

5000 VA

7500 VA, 10s

21.7 A

21.7 A

≤ 10 ms

< 3%

99.90%

97% / 97.6%

94.70%

●

● / ●

●

●

●

● / ●

●

I / AC: III; DC: II

5000 W*1

5000 VA*1

5000 VA*1

21.7 A*2

22.7 A*2

6000 W

6000 VA

6000 VA

26.1A

27.3A

≥0.99 / 0.8 leading to 0.8 lagging

494 / 420 / 195 mm

21.5 kg

-25 °C ... +60 °C

30 dB(A)

< 10 W

Natural convection

IP66

4K4H

100%

4000m (>3000m power derating)

THE PEOPLE'S REPUBLIC OF CHINA

LED & App

RS485 / CAN

RS485

WIFI stick

DRM

● / ●

F

e

a

t

u

r

e

s

G

e

n

e

r

a

l

d

a

t

a

S

a

f

e

t

y

p

r

o

t

e

c

t

i

o

n

E

f

f

i

-

E

P

S

o

u

t

p

u

t

A

C

i

n

p

u

t

A

C

o

u

t

p

u

t

c

i

e

n

c

y
