Modulo FV 550 W mono Halfcut | Black-white
Cod. 2032100006
Mono S4 Halfcut | Black-White
550 W / 555 W / 560 W - Projektmodul
Electrical data under STC
(Standard Test Conditions: 1000 W/m2, 25 °C, AM 1.5)
Logistic
Dimension pallet (L/W/H)
Weight pallet
Modules per pallet
Modules per truck
Modules per
container [40‘ HC]
2023
Module performance
100 %
90%
Q2/2023
Q1/2023
Q4/2022
Rated power
Sorting limits of performance
Voltage
Open circuit voltage
Current
Short-circuit current
Efficiency
Temperature data
P
max
U
MPP
U
OC
I
MPP
I
T
K
(P
MPP
)
T
K
(U
OC
)
T
K
(I
SC
)
Operating temperature
Nominal operating cell temperature
Power temperature coefficient
Voltage temperature coefficient
Current temperature coefficient
Further information
Number of cells
Size of cell
Module dimensions
Type of Frame
Max. system voltage
Reverse current loading capability
Glass thickness
Weight
Module connection
Junction box rating
Allowable Hail Load
Snow load
BB
SC
15-year product warranty, 25-year linear performance warranty according to our additional warranty conditions for solar power
modules of the “Mono S4” product series, which we will gladly send you.
Due to the tolerance of the anti-reflective coating, colour differences in the solar modules may occur.
Subject to technical modifications with corresponding follow-up certifications. Errors excepted. Illustration similar.
Valid as of: 14.09.2023
0
5
10
15
20
25
years
Linear performance warranty
Standard tiered warranty
560
14
490
12
800W/m2
420
10
600W/m2
350
8
280
6
400W/m2
210
4
200W/m2
140
2
70
0
0
5
10
15
20
25
30
35
40
45
50
Voltage(V)
1000W/m2
Solar Fabrik GmbH
Hermann-Niggemann-Str. 7–9
63846 Laufach
Germany
+49 (0)6093 20770-0
info@solar-fabrik.de
www.solar-fabrik.de
23
550W
555 W
560 W
0/+3 %
0/+3 %
0/+3 %
41.60 V
41.80 V
42.00 V
49.80 V
50.00 V
50.20 V
13.23 A
13.29 A
13.33 A
13.99 A
14.05 A
14.11 A
21.28 %
21.48 %
21.67 %
– 40° C ~ + 85° C
41° C ± 3° C
– 0.36 %/°C
– 0.28%/°C
0.05 %/°C
Linear performance warranty for guaranteed added value
80%
144 monocrystalline half cells (6 x 24)
182 x 91 mm
2279 x 1134 x 35 mm
Anodized aluminium alloy
1500 V
25 A
3.2 mm
approx. 27 kg
MC4 or similar, 4.0 mm2,
cable length: (+) ≥ 1200 mm, (−) ≥ 1200 mm
IP68
25 mm iceball with velocity
of 23 m/s
5400 Pa =^ 550 kg/m
2
C
u
r
r
e
n
t
(
A
)
P
o
w
e
r
(
W
)
Mono S4 144 HC V XXX
(half cell module)
Note:
Ensure correct polarity!
1134mm
35mm
H
�
(Backside)
Note: mm
Junction Box
2
2
7
9
m
m
Mono S4 Halfcut | Black-White
550 W / 555 W / 560 W - Projektmodul
The Solar Fabrik Mono S4 Halfcut module
with a max. system voltage of 1500V is monocrystalline
and available in the 550 W, 555 W and 560 W power classes.
+
Half cell modules — High efficiency, high
safety, high reliability
+
Highly transparent self-cleaning glass
+
High performance under low light conditions
erful Future
+
Resistant to environmental influences:
Passed salt mist & ammonia test
+
Multibusbar-technology
+
Area utilization 216.69 W/m
2
at 560 W
+
German warranty
By separating the cells into two equal parts (half-cut techno-
logy), the module achieves a higher output than a full-cell mo-
dule. The current flow in the cell is halved and the power loss
is thus reduced. Due to the changed cell arrangement, the
Mono S4 Halfcut module offers further advantages. On the
one hand, the improved low-light behaviour and, on the other
hand, the behaviour in the case of shading. If a full-cell modu-
le no longer produces any power when shaded, the Solar Fa-
brik Mono S4 Halfcut can still achieve up to 50% power.
The multibusbar technology enables even higher perfor-
mance, higher reliability and higher (electrical) stress capa-
city of the modules.
2023
Your specialist dealer:
232/114/125 cm
approx. 867 kg
31
682
620
Q2/2023
15
YEARS
25
www.solar-fabrik.de
w
