VENTILATION AND AIR TREATMENT SYSTEM

S

SYSTEMS DE VENTILATION ET TRAITEMENT DE L’AI

R

SISTÈMAS DE VENTILACIÓN Y TRATAMIENTO DEL AIRE

SISTEMI DI VENTILAZION

E

E TRATTAMENTO DELL’ARI

A

23

1

SPECTRE: Recuperatore di calore decentralizzato a

flusso alternato

SPECTRE: Decentralized alterning-flow heat recovery unit

I

T

FR

Accessori disponibili per SPECTRE

La versione BASE 1.0 non include il telecomando, in quanto è dotato di

comandi a bordo (ON/OFF + 2 velocità)

.

La versione ACTIVE 2.0 e 3.0 includono invece un telecomando con displa

y

grazie al quale è possibile anche regolare il grado di umidità, inserire l

a

funzione notte e gestire

fino a 16 unità in un sistema Master/Slave con un

a

semplice configurazione dip switches.

E’ possibile acquistare separatamente anche il pannello di controllo remoto

con display che include le stesse funzionalità del telecomando e la version

e

con sonda CO2.

Accessoires disponibles pour SPECTRE

La version BASE 1.0 n'inclut pas la télécommande, puisqu’ elle est équipée d

e

commandes intégrées (ON/OFF + 2 vitesses)

.

Les versions ACTIVE 2.0 et 3.0 comprennent une télécommande avec écra

n

grâce à laquelle il est également possible de régler le niveau d'humidité

,

d'activer la fonction nuit et de gérer jusqu'à 16 unités dans un systèm

e

Master/Slave avec une simple configuration de commutateurs DIP

.

Il est également possible d'acheter séparément le panneau de commande à

distance avec écran qui comprend les mêmes fonctions que la télécommande

et la version avec sonde CO2

.

E

N

E

S

Accessories available for SPECTRE

The BASE 1.0 version does not include the remote-control, as it is equipped

with on-board controls (ON/OFF + 2 speeds)

.

The ACTIVE 2.0 and 3.0 versions include a remote-control with display thanks

to which it is also possible to adjust the humidity level, activate the night

function and manage up to 16 units in a Master/Slave system with a simple

dip switch configuration.

It is also possible to purchase the remote-control panel with display separatel

y

which includes the same functions as the remote-control and the version wit

h

CO2 probe.

Accesorios disponibles para SPECTR

E

La versión BASE 1.0 no incluye el mando a distancia, ya que está equipada

con controles integrados (ON/OFF + 2 velocidades)

.

Las versiones ACTIVE 2.0 y 3.0 incluyen un mando a distancia con displa

y

gracias al que también es posible ajustar el nivel de humedad, activar l

a

función noche y gestionar hasta 16 unidades en un sistema Master/Slave con

una sencilla con

figuración de dip switch

.

También es posible comprar por separado el panel de control remoto co

n

display que incluye las mismas funciones que el mando a distancia y la versión

con sonda de CO2.

SPECTRE 2.0 - 3.0

INCLUSO / INCLUDE

D

SPECTRE 2.0 - 3.0

OPZIONALE / OPTIONA

L

MODALITÀ AUTOMATICA / AUTOMATIC MODE

L’unità viene gestita in automatico come da impostazioni di fabbrica

.

The product runs in automatic mode as per factory settings.

SORVEGLIANZA / SURVEILLANCE MODE

L’unità resterà spento ma attivo grazie ai suoi sensori; se i valor

i

cambieranno (es. umidità) il prodotto ricomincerà a lavorare.

The unit remains in sleep mode but keeps the sensors activated; in case

of parameters like humidity change, it will automatic start running.

MODALITÀ FLUSSO D’ARIA / AIR FLOW DIRECTION

Funzione attivabile solo se ci sono almeno due unità installate:permett

e

l’immissiono l’estrazione dell’aria in contemporanea per un periodo limitato

.

This function is available if the products are at least two: it allows to only

intake or only extract air simultaneously for a desired time

.

MODALITÀ MANUALE / MANUAL FUNCTIO

N

Modalità di funzionamento con velocità impostata manualment

e

(i sensori restano esclusi).

Running mode with heat recovery at the manually set speed

(the sensors excluded)

.

VELOCITA’ / SPEED

Regolazione dei 3 livelli di velocità pre-impostati.

3 adjustable speed levels.

IGROSTATO / HUMIDITY LIMIT SELECTION

Sensore di umidità con 3 livelli impostati: min. 40%, medio 55%, max. 70%.

Humidity sensor with 3 set levels: min 40%, medium 55%, max 70%.

FUNZIONE BOOST / BOOST FUNCTION

Permette di espellere aria alla velocità max per un tempo determinato.

It allows the air extraction at the maximum speed for a certain time.

FILTRO / FILTER

Dopo aver effettuato la pulizia ordinaria, premere il tasto per ripristinar

e

l’operatività.

After 3000 hours operations the unit requires ordinary maintenance. Pushing

this button, after maintenance, the normal operation can be restored.

FUNZIONE NOTTE / NIGHT FUNCTION

Permette di abbassare ulteriormente il flusso dell’aria e la rumorosità nelle ore

notturne.

It allows to minimize the flow rate and noise during night.

Catalogo I Catalog I Catalogue I Catálogo 2024

TECNOGAS

231
