monorotaie per porte scorrevoli lineari
single rails for linear sliding panels
monorotaia a parete / single wall rail
Velaria / Soho / Stripe / Sail / Daimon
Graphis plus / Graphis light / Siparium
monorotaia a parete contro soffitto / single wall rail against the ceiling
Maxi
Velaria / Soho / Stripe / Sail / Daimon
Graphis plus / Graphis light / Siparium
6
90
Maxi
90
90
min. 100
h vano
opening h
min. 100
h vano
opening h
6
90
h vano
opening h
h vano
opening h
16 3
8
14
68
10 50
8
68
16 3
8
14
68
10 50
8
68
10
10
10
10
lunghezze mm
length mm
30 alluminio, 13 nero,
14 brown, 16 bianco latte
ecolorsystem laccato
ecolorsystem lacquered
19 rovere termotrattato,
15 noce, 711 rovere
profili di copertura
covering profiles
30 alluminio, 13 nero,
14 brown, 16 bianco latte
ecolorsystem laccato
ecolorsystem lacquered
1000
1500
2000
2500
3000
3500
4000
4500
5000
5500
6000
monorotaia a soffitto / single ceiling rail
Velaria / Soho / Stripe / Sail / Daimon
Maxi
Graphis plus / Graphis light / Siparium
monorotaia a soffitto contro parete / single ceiling rail against the wall
Velaria / Soho / Stripe / Sail / Daimon
Maxi
Graphis plus / Graphis light / Siparium
hsoffitto
ceiling h
25
25
25
25
6
hsoffitto
6
6
hsoffitto
6
hsoffitto
ceiling h
ceiling h
90
90
90
90
10
10
10
10
ceiling h
14 38 14
66
66
64
64
8
50
8
12 38 14
6
50 8
lunghezze mm
length mm
30 alluminio, 13 nero,
14 brown, 16 bianco latte
ecolorsystem laccato
ecolorsystem lacquered
19 rovere termotrattato,
15 noce, 711 rovere
profili di copertura
covering profiles
30 alluminio, 13 nero,
14 brown, 16 bianco latte
ecolorsystem laccato
ecolorsystem lacquered
1000
1500
2000
2500
3000
3500
4000
4500
5000
5500
6000
65
