CONTI+ Redox and pH measuring unit, with temperature measurement

Redox and pH measuring unit with temperature measurement for the determination of

redox potential, pH value and water temperature

•

LC Display with Battery status

•

Hold-button for value fixing

•

Auto-off funktion (after 8 min)

•

Waterproof and swimmable

•

Factory calibration, changeable electrode

Technical data:

Redox potential measuring range:

Redoxpotentialmeasuringresolution:

Redox potential accuracy:

Temperature measuring range:

Temperature measuring resolution:

Temperature accuracy:

Battery type:

Dimensions (WxHxD):

Weight:

Note:

± 1000 mV

1mV

± 2 mV

-5,0 to 60 °C

0,1 °C

± 0,5 °C

1,5 V

40x163x26 mm

0,1 kg

Measuring unit may need to be calibrated before use.

Description

Version

Article number

CONTI+ Redox measuring unt

with temperature measurement

CONB21000010

CONTI+ photometer for the determination of DPD, pH value

CONTI+ photometer for the determination of free active chlorine (DPD measurement),

bound or total chlorine and pH value of drinking and swimming pool water.

Bluetooth 4.0 for wireless synchronisation of measurement results with computer or

smartphone via software or app.

Consisting of:

•

Storage box, waterproof

•

Photometer, light protection cap

•

Stirring rod, syringe and 3 x AAA batteries

•

Reagent tablets 30 x DPD N° 1

•

10 x DPD N° 3, 20 x Phenol Red, 10 x CYA-Test

•

10 x Alkalinity-M

Technical data:

Temperatur Messbereich:

Dimensions (WxHxD):

Schutzart:

5–45 °C

70x260x130 mm

IP68

Description

Version

Article number

CONTI+ Photometer

digital

CONB21000020

Redox measuring unit, with temperature measurement

Photometer
