Conti - 2021-2022

lino urinal flush valve U10

120

140

Power supply

Battery

Concealed mains power

supply

VARIOconnect

info@conti.plus | www.conti.plus | CONVKF1010EN | valid from 07/2021 | Subject to change without prior notice

355

lino urinal flush valve U10, with IR sensor, chromed/white -

final installation set

Touchless, electronically controlled urinal flush valve for concealed installation:

•

Sturdy front plate made of metal, chromed

•

Infrared sensor (with automatic setting feature!), microprocessor

•

Reliable solenoid valve (extremely minimal level of water pressure surge)

•

Dynamic sensor: constantly adjusts the optimum of range

•

Temporary-off (cleaning) and short-on (manual flush) activatable with Click

•

Flush time and sensor sensitivity adjustable with Click

•

24- or 48-hour hygienic flush and pre-rinse activatable with Click

•

Variable installation in combination with urinal shell set U2L or U3L (not included)

•

Stop valve and filter in concealed installation box

•

Compatible with CNX and Service APP: control of stored operational data, settings and

control functions

Battery:

Mains supply:

VARIOconnect:

Operating pressure:

Flow rate (approx.):

Filter:

Sensor-sensitivity:

Flush time:

Temporary-off (approx.):

Residence time (approx.):

Engineering standards:

Necessary accessory:

Note:

6 V Lithium CRP2 - standard; life time up to 4 years

Plug-in transformer 110-240 V 50/60 Hz / 6 V

For single- and multiple power supply and data connection

(Connection to CNX and Service APP - see accessories)

0,3-10 bar

20 l/min / 5,3 gpm (3 bar)

0,5 mm mesh size

Automatic self-adapting sensor technology

Pre-set approx. 7 sec. (adjustable with Touch 2-30 sec.)

2 min. (fixed)

10 s (fixed)

DIN EN 200;

220.022.00 urinal shell set U3L or

220.025.00 urinal shell set U2L

When integrated into the CNX Water Management System,

the CNX Converter 6 V must be ordered separately.

When using the Service APP, the BLE Converter must be ordered

separately.

Colour

Article number

Front plate: chromed / Window: white

220.000.43

Front plate: white / Window: white

220.000.33

Front plate: chromed / Window: white

220.010.43

Front plate: white / Window: white

220.010.33

Front plate: chromed / Window: white

220.016.43

Front plate: white / Window: white

220.016.33
