CONBOX raw-assembling set for concealed shower, thermostat, DN15

Raw-assembling set for mechanical and electronic shower equipment based on the adaptive

multifunctional water path CONGENIAL with thermostat, designed as flush-mounted show-

er in nominal width DN15. Application area in new construction and renovation in public,

semi-public and commercial sanitary facilities.

Consisting of:

•

Concealed shower box CONBOX

•

Recessed enclosure: ABS, dimensions (WxHxD minimum): 232x272x96 mm, self-supporting

•

Fastener brackets for mounting material with max. diameter 8 mm

•

Wall outlet diameter 230 mm can be cut to length of tile front edge, condensate drain slope

•

Sealed and sound-insulated brass entrances and exits, inlet with shut-off valves R 1/2

•

Detachable connecting coupling for exchange the flushing piece on the water path

•

Mounting depth with final assembly set: 96-110 mm

•

Flushing piece: ABS, waterless and hygienically, tested for leakage

•

Protective plug: EPS, dimension (ØxD) 226x40 mm

•

Gasket ring: PE, dimensions (WxH) 450x450 mm, with expansion zone

•

Connection to cold and hot water

Description

Connection

Nominal width

Article number

CONBOX raw-assembling set

for concealed shower, thermostat

R 1/2

DN15

CONR0112

CONBOX FLANGE raw-assembling set for concealed shower, thermostat,

DN15 with bonding flange

Raw-assembling set for mechanical and electronic shower equipment based on the adaptive

multifunctional water path CONGENIAL with thermostat, designed as flush-mounted shower

in nominal width DN15. Application area in new construction and renovation in public, semi-

public and commercial sanitary facilities.

Consisting of:

•

Concealed shower box with bonding flange CONBOX FLANGE

•

Recessed enclosure: ABS, dimensions (WxHxD minimum): 272x232x96 mm, self-supporting

•

Fastener brackets for mounting material with max. diameter 8 mm

•

Wall outlet diameter 230 mm can be cut to length of tile front edge, condensate drain slope

•

Sealed and sound-insulated brass entrances and exits, inlet with shut-off valves R 1/2

•

Detachable connecting coupling for exchange the flushing piece on the water path

•

Mounting depth with final assembly set: 96-110 mm

•

Flushing piece: ABS, waterless and hygienically

tested for leakage

•

Protective plug: EPS, dimension (ØxD) 226x40 mm

•

Bonding flange made of ABS, (ØxD) 430x12 mm

•

Connection to cold and hot water

Description

Connection

Nominal width

Article number

CONBOX FLANGE raw-assembling set

for concealed shower with bonding flange,

thermostat

R 1/2

DN15

CONR1112

CONBOX raw-assembling set for concealed shower, DN15

CONBOX FLANGE raw-assembling sets for concealed shower, DN15
