70351P

Two-way strainer filter for diesel, fuel oil and air with aluminium cover and transparent bowl. Screw

valve on suction and check valve on return.

Max. temperature: 50°C. PN 2. NBR gaskets. 3/8” connections.

DEVICES FOR DIESEL AND FUEL OIL

CHAPTER 3

Type

70351/0015PP

70351/006P

70351/01P

Part number

001.0061.001

001.0061.003

001.0061.004

Dimensions on page 387

RG2

Cartridge type

Paper filter

Stainless steel

pleated cartridge

Stainless steel

pleated cartridge

Filtration

15 μ

60 μ

100 μ

Q.ty/

Box/

Box

Carton

10

10

10

10

10

10

€/unit

Two-way strainer filter for diesel, with large filtration area, bowl fastened with ring-nut. Screw valve on

suction and check valve on return, complete with fixing bracket. CW617N brass body and ring-nut.

Transparent plastic bowl. 3/8” F connections with bushes for Ø 6x8, 8x10 and 10x12 mm pipes.

Part number Cartridge type Filtration

Q.ty/

Box/

€/unit

Box

Carton

0130100

-

260μ

1

32

Dimensions on page 387

RV2

Two-way strainer filter for diesel with screw valve on suction and check valve on return, complete

with fixing bracket. CW617N brass body and ring-nut. Transparent plastic bowl. 3/8” F connections

with bushes for Ø 6x8, 8x10 and 10x12 mm pipes. Burner side connections: 3/8” F.

Type

RG2

Type

RV2

Part number Cartridge type Filtration

Q.ty/

Box/

Box

Carton

0133100

-

200μ

1

50

Dimensions on page 387

RV1

€/unit

One-way strainer filter for diesel, with screw valve and fixing bracket. CW617N brass body.

Transparent plastic bowl. Burner side 3/8” F connections, with bushes for Ø 6x8, 8x10 and 10x12

mm pipes. Tank side 3/8” F connection. Filtering capacity 200 microns.

Type

RV1

Part number Cartridge type Filtration

Q.ty/

Box/

Box

Carton

0135100

-

200μ

1

50

Dimensions on page 387

V1

One-way strainer filter for diesel, like RV1 but without shut-off valve.

Part number Cartridge type Filtration

Q.ty/

Box/

Box

Carton

€/unit

€/unit

Type

V1

0138100

-

200μ

1

50

71
