CHAPTER 2 DEVICES FOR GAS
PROTECTION DEVICE
GUA
Yellow, spiral-reinforced, self-extinguishing flexible sheath with smooth internal surface for protecting
gas pipes, as laid down in UNI-CIG 7129-08 and UNI-CIG 7131. PVC sheath. Crush-resistance: To
320 N. Temperature-resistance: -10 to 70°C. Self-extinguishing to UL 94 class VO. Minimum bend
radius less than 3 times the diameter (empty sheath). Absolute electrical insulation against stray
currents. Absorbs the thermal expansion of gas supply pipes thereby preventing the formation of
cracks in walls and floors.
Type
GUA
GUA
GUA
GUA
GUA
GUA
GUA
GUA
GUA
GUA
Part number
0917020
0917022
0917025
0917028
0917030
0917032
0917035
0917040
0917050
0917060
External
Diameter
24.7 mm
27mm
30.3 mm
33.3 mm
35.5 mm
37.8 mm
40.7 mm
46.2 mm
57mm
68 mm
Internal Diam-
Q.ty/Box
Box/Car-
eter
ton
€/unit
20 mm
22 mm
25mm
28mm
30 mm
32 mm
35 mm
40 mm
50 mm
60 mm
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
TECHNICAL NOTE - Protection of gas supply pipes
Cavity feed-through.
Hollow brick, concrete, and prefabricated panel feed-through.
Floor and ceiling slabs.
Crossover or parallel runs of water supply pipes.
Wherever it is necessary to insulate metal pipes against stray currents.
Italian standards UNI 7129-08 and UNI 7131-99 governing domestic gas supply systems supplied by the distribution network (UNI 7129) or with
LPG (UNI 7131) require gas supply pipes to be inserted in a protective sheath. UNI 7129-08, 3.3.1.4.... omissis .... The internal diameter of the
aforementioned sheaths must be at least 10 mm larger than the external diameter of the pipe.
SELF-EXTINGUISHING SHEATH WITH SPIRAL-REINFORCED EXTERNAL SURFACE AND SMOOTH INTERNAL SURFACE
FOR PROTECTING GAS SUPPLY PIPES
mm
mm
g/m
20
10
100
22
12
107
25
15
114
28
18
140
30
20
177
32
22
220
35
25
274
40
30
350
50
40
420
60
50
517
Sheath
Part N°
0917020
Internal diameter
of sheath
Nominal diameter
of iron supply pipes
Weight
0917022
0917025
0917028
0917030
0917032
0917035
0917040
0917050
0917060
