Applicazioni
Applications
Pressione Max
Max pressure
Temperatura
Temperature
Forature
Drilling
Misure
Sizes
Corpo
Body
Certificazioni e conformità
Certifications and
declaration of conformity
12.000
a membrana / diaphragm valve
13.000
a pistone / piston valve
A
Dimensioni (mm) / Dimensions (mm)
B
DN
50
65
80
100
125
150
200
250
300
400
500
600
700
800
A
230
260
310
350
350
480
620
730
850
1100
1250
1450
1650
1850
H
330
375
420
465
570
630
780
90
1110
1215
1335
1455
1530
1605
B
340
360
400
420
460
500
560
600
680
780
920
1080
1180
1280
Peso (kg) / Weight (kg)
DN
50
65
80
100
125
150
200
250
300
400
500
600
700
800
kg
20
24
30
43
48
90
142
230
380
550
860
1
.
100
1
.
450
1
.
900
40 bar
0 +70 °C
PN16/25/40
DN
50 - 800
ghisa grigia / cast iron
