Applicazioni

Applications

Campo di pressione

differenziale controllabile

Controllable differential

pressure range

Pressione Max

Max pressure

Temperatura

Temperature

EKOFLUX.ML

EKOFLUX.MH

Forature

Drilling

Misure

Sizes

16 bar

-10 +120 °C

PN 16

Certificazioni e conformità

Certifications and

declaration of conformity

Corpo

Body

ghisa grigia / cast iron

ottone, acciaio inox, EPDM / brass, stainless steel, EPDM

Dimensioni (mm) / Dimensions (mm)

DN

65

80

100

125

150

A

B

0,2 – 1 bar

0,8 – 1,6 bar

DN

65 - 150

DN

65 - 100

www.brandonivalves.com

85

A

290

H

615

B

200

C

185

310

350

716

740

242

242

200

220

400

480

803

841

242

242

250

285

Peso (kg) / Weight (kg)

DN

65

80

100

125

150

kg

24,2

30,6

36,1

51

80
