Applicazioni

Applications

Campo di pressione

differenziale controllabile

Controllable differential

pressure range

Pressione Max

Max pressure

Temperatura

Temperature

EKOFLUX.DL

EKOFLUX.DH

Forature

Drilling

Misure

Sizes

16 bar

-10 +120 °C

PN 16

Certificazioni e conformità

Certifications and

declaration of conformity

Corpo

Body

ghisa grigia / cast iron

ottone, acciaio inox, EPDM / brass, stainless steel, EPDM

Dimensioni (mm) / Dimensions (mm)

DN

65

80

100

125

150

B

A

0,2 – 1 bar

0,8 – 1,6 bar

DN

65 - 150

DN

65 - 100

www.brandonivalves.com

83

A

290

H

480

C

185

B

200

310

350

400

480

582

614

711

760

200

220

250

285

242

242

242

242

Peso (kg) / Weight (kg)

DN

65

80

100

125

150

kg

21,6

28,1

33,6

46,4

75,4
