VERSIONI DISPONIBILI | VERSIONS AVAILABLE

BxH

Ugelli per diffusore

Nozzles for diffuser

mm

N°

200x100

3

300x100

5

400x100

7

500x100

9

600x100

11

700x100

13

800x100

15

1000x100

19

1200x100

23

300x150

10

400x150

14

500x150

18

600x150

22

700x150

26

800x150

30

1000x150

38

1200x150

46

300x200

15

400x200

21

500x200

27

600x200

33

700x200

39

800x200

45

1000x200

57

1200x200

69

400x250

28

500x250

36

600x250

44

700x250

52

800x250

60

1000x250

76

1200x250

92

500x300

45

600x300

55

700x300

65

800x300

75

1000x300

95

1200x300

115

File ugelli

Nozzle file

N°

1

1

1

1

1

1

1

1

1

2

2

2

2

2

2

2

2

3

3

3

3

3

3

3

3

4

4

4

4

4

4

4

5

5

5

5

5

5

GUR

SC

CT

PBZ1

PBZI1

PBZ2

PBZI2

GUR

107

D

I

F
