SERIE INOX 304

inox 304 line

80

108

90

Barra ribaltabile con piastra lunga

e frizione

folding supporting bar with long fixing plate

testo di capitolato:

barra di sicurezza, tipo ribaltabile, con frizione per bloccaggio verticale e

sistema antinfortunistico, costituita da un solo pezzo, senza giunzioni, rea-

lizzata in acciaio inox 304 rifinita o rivestita con materiale antiusura antiset-

tico, tubo Ø32, completo di: piastra in a cciaio inox 304 a 4 fori per fissaggio

a parete, perno diunione Ø8, frizione in materiale sintetico termoplastico.

Capacità di carico 150kg. a norma UNI-CNR 1 0021/85 - 10011/85.

misura ... cm Tipo Goman INOX codice ...

specifications:

folding supporting bar with friction for vertical block constituted by a

single piece, without joints, realized in stainless steel 304, tube Ø32

consisting of: stainless steel 304 plate, with 4 holes for fixing to wall, pivot

Ø8, thermoplastic friction.

Capacity 150 kg. in respect of UNI-CNR 10021/85 - 10011/85.

measure ... cm Goman STAINLESS STEEL Type code ...

80

108

90

Barra ribaltabile con piastra lunga,

frizione e portarotolo

folding supporting bar with long fixing plate

and paper holder

testo di capitolato:

barra di sicurezza, tipo ribaltabile, con frizione per bloccaggio verticale e

sistema antinfortunistico, costituita da un solo pezzo, senza giunzioni, rea-

lizzata in acciaio inox 304 rifinita o rivestita con materiale antiusura antiset-

tico, tubo Ø32, completo di: piastra in a cciaio inox 304 a 4 fori per fissaggio

a parete, perno diunione Ø8, frizione in materiale sintetico termoplastico.

Capacità di carico 150kg. a norma UNI-CNR 1 0021/85 - 10011/85.

misura ... cm Tipo Goman INOX codice ...

specifications:

folding supporting bar with friction for vertical block constituted by a

single piece, without joints, realized in stainless steel 304, tube Ø32

consisting of: stainless steel 304 plate, with 4 holes for fixing to wall, pivot

Ø8, thermoplastic friction.

Capacity 150 kg. in respect of UNI-CNR 10021/85 - 10011/85.

measure ... cm Goman STAINLESS STEEL Type code ...

184

184

Ø32x15

GREZZO

SATINATO LUCIDO

ROUGH

SATINY

SHINY

XB12/92

XB12/91

XB12/93

XB13/92

XB13/91

XB13/93

XB70/92

XB70/91

XB70/93

BIANCO

WHITE

XB12/01

XB13/01

XB70/01

Ø32x15

GREZZO

SATINATO LUCIDO

ROUGH

SATINY

SHINY

XB14/92

XB13/91

XB13/93

XB71/92

XB70/91

XB70/93

BIANCO

WHITE

XB13/01

XB70/01

cm 60 (a)

cm 80 (a)

cm 70 (a)

a

a

1

8

0

2

6

5

2

0

9

2

0

9

cm 80 (a)

cm 70 (a)

63
